Parker SSD DC590+ series 2-quadrant variable speed DC drives 591P-53235010-P00-U4A0

Parker SSD DC590+ series 2-quadrant variable speed DC drives 591P-53235010-P00-U4A0

The 590P Series DC Drive  is designed for use in a suitable enclosure, with associated control equipment. The unit accepts standard
three-phase ac supply voltages in the range 110V to 660V, depending upon the model, and is suitable for the powering of DC shunt
field and permanent magnet motors, providing controlled dc output voltage and current for armature and field.

The coding circuitry adjusts automatically to accept supply frequencies between 45-65Hz and possesses high immunity to
supply-borne interference. The armature controllers are phase rotation insensitive.

590P

590P/0015/500/0011/UK/AN/0/230/0   15A 500V

590P/0035/500/0011/UK/AN/0/230/0   35A 500V

590P/0040/500/0011/UK/AN/0/230/0   40A 500V

590P/0070/500/0011/UK/AN/0/230/0   70A 500V

590P/0110/500/0011/UK/AN/0/230/0   110A 500V

590P/0165/500/0011/UK/AN/0/230/0   165A 500V

590P/0180/500/0011/UK/AN/0/230/0   180A 500V

590P/0270/500/0011/UK/AN/0/230/0   270A 500V

590P/0380/500/0041/UK/AN/0/230/0   380A 500V

590P/0500/500/0041/UK/AN/0/230/0   500A 500V

590P/0725/500/0041/UK/AN/0/230/0   725A 500V

590P/0830/500/0041/UK/AN/0/230/0   830A 500V

590P/1580/500/0041/UK/AN/0/230/0   1580A 500V

590P/2200/500/0011/UK/AN/0/230/0   2200A 500V

590P/2700/500/0011/UK/AN/0/230/0   2700A 500V

591P

591P/0015/500/0011/UK/AN/0/230/0   15A 500V

591P/0035/500/0011/UK/AN/0/230/0   35A 500V

591P/0040/500/0011/UK/AN/0/230/0   40A 500V

591P/0070/500/0011/UK/AN/0/230/0   70A 500V

591P/0110/500/0011/UK/AN/0/230/0   110A 500V

591P/0165/500/0011/UK/AN/0/230/0   165A 500V

591P/0180/500/0011/UK/AN/0/230/0   180A 500V

591P/0270/500/0011/UK/AN/0/230/0   270A 500V

591P/0380/500/0041/UK/AN/0/230/0   380A 500V

591P/0500/500/0041/UK/AN/0/230/0   500A 500V

591P/0725/500/0041/UK/AN/0/230/0   725A 500V

591P/0830/500/0041/UK/AN/0/230/0   830A 500V

591P/1580/500/0041/UK/AN/0/230/0   1580A 500V

591P/2200/500/0011/UK/AN/0/230/0   2200A 500V

591P/2700/500/0011/UK/AN/0/230/0    2700A 500V
