Home > Products > Three Phase Brushless Alternator > 34kw 1500rpm 3 Phase Brushless Alternator Double Bearing Generator

34kw 1500rpm 3 Phase Brushless Alternator Double Bearing Generator

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Werna		Place of Origin	China
Model Number	WR224C

Product Description

Delivery Time:Within 10 days
Certification:CE,ISO9001,SASO

34kw 1500rpm 3 Phase Brushless Alternator Double Bearing Generator

Quick detail:

Name	ALTERNATOR	Brand Name	WERNA
Color	According to the international standard color card	Feature	AC brushless synchronous excitation alternator
Power	34KW	Certificate	CE,ISO9001,SASO

Specication:

manufacture	Wuxi City ,Jiangsu Prov ,China making alternators
Output type	AC Three Phase Brushless generator
Terminal	12 / 6 Wire
Rated Voltage	110V~690V
Frequency	50Hz
Speed	1500RPM
Mounting Dimension	Stamford Type
Winding? pitch	2/3 pitch
Excitation	Brushless, self-excited, synchro
Insulation Class	H

Description:

with Long experience in manufacturing alternator / ac generator,ranging6.5~120kw

for prime or standby use, more than 50 different models, with 50Hz or 60Hz frequency, Single bearing or Double bearing, brushless, Self-excited. Abounds with almost every model in stock.

1) Protection class IP23, insulation class H.

2) The standard winding protection can accept up to 95% relative humidity and the alternator is suitable for indoors marine applications.

3) The brushless alternator is equipped with reliable AVR.?? MX321, MX341, AS440, SX440, SX460, etc

4)? Adapted to excitation systems, powered by transistors and fulfilling perfect regulation.

5) The power factor ranges from 0.8 to 1.?

6) Telephone influence factor is less than 50, according to NTMA.????

7) Transient voltage dip for rated step load at 0.8 power factor is less than 18%.?

8) Overload standard according to NEMA.

9) All generator statore are wound to 2/3 pitch.??

Parameter:

Werna Type	3Phase 50Hz 1500rpm	Shaft length	Copper total weight	Core length
380V~415V
KVA	KW	mm	kgs	mm
WR224C	42.5	34	668.2	23.45	130
WR224D	50	40	668.2	25.35	160
WR224E	60	48	758.2	28.24	180
WR224F	72.5	58	758.2	32.84	240
WR224G	85
