11mm Load 80kN Anti-twist Braided Steel Wire Rope transmission Line Stringing Pilot Rope
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Anti Twisting Wire Galvanized Steel Line Stringing Rope for Overhead Transmission Line 13mm 120kN
-
Braided Steel 15mm Anti twist Wire Rope for 158kN High Voltage Cable Stringing
-
18mm 200kN Galvanized Steel Anti twist Wire Rope Conductor Stringing ROpe 12 Strands 6 Squares
-
Galvanized Steel Anti Twist Braid Rope / Anti Twist Wire Rope for Transmission Line Stringing
-
2 x 70kN Double Bundle Overhead Line Stringing Equipment , Hydraulic Puller Tensioner
-
380kN 38T Overhead Transmission Line Stringing Equipment / Conductor Hydraulic Cable Puller
Product Details
| Brand Name | Boyu | Place of Origin | China | |
| Model Number | YL11-12x19 |
Product Description
Certification:ISO9001
11mm Load 80kN Anti-twist Braided Steel Wire Rope transmission Line Stringing?Pilot Rope
Quick details:
1. Transmission Line Stringing Accessories
2. Anti-twist Braided?Steel Wire Rope Pilot Rope
3. Size: 11mm Length: 1000m
4. Breakage load: 80kN
5. Size available: 9~30mm
6. 6 Squares 12 Strands
7. Reel diameter: 1100mm
Description
Anti-twist braided wire rope with high strength hot dip galvanized steel quality air processed by the special process of special woven rope line. It has high strength, good flexibility, corrosion rust-proof, not to fight the golden hook, and difficult to tie, long life and so on. Tension applied to pay-off power lines construction, lifting equipment with the balance shaft and the tail rope of mine, port and other major lift crane wire rope does not rotate when the required place.
|
Item no. |
Normal Diameter (mm) |
Structure |
Ref. Weight (kg/m) |
Breakage tension(kN) |
||
|
Rope structure |
||||||
|
1x19 |
1x19W |
T25 T29 |
||||
|
YL9-12x19 |
10 |
6 Squares 12 Strands |
0.297 |
50 |
55 |
|
|
YL11-12x19 |
11 |
6 Squares 12 Strands |
0.480 |
70.5 |
80 |
|
|
YL13-12x19 |
13 |
6 Squares 12 Strands |
0.630 |
105 |
120 |
|
|
YL15-12x19 |
15 |
6 Squares 12 Strands |
0.925 |
140 |
158 |
|
|
YL18-12x19 |
18 |
6 Squares 12 Strands |
1.150 |
185 |
210 |
|
|
YL20-12x19 |
20 |
6 Squares 12 Strands |
1.320 |
250 |
||
|
YL22-12XT25 |
22 |
6 Squares 12 Strands |
1.822 |
320 |
||
|
YL24-12xT25 |
24 |
6 Squares 12 Strands |
2.034 |
360 |
||
|
YL28-12xT29 |
28 |
6 Squares 12 Strands |
2.882 |
480 |
||
|
YL30-12xT29 |
30 |
6 Squares 12 Strands |
3.120 |
540 |
||
|
YL20-18x19 |
20 |
6 Squares 18 Strands |
1.598 |
280 |
300 |
|
|
YL22-18XT25 |
22 |
