Home > Products > Surface Roughness Tester > ANSI 2RC Filter RoughScan Portable Surface Roughness Tester Piezo-Electric Probe
ANSI 2RC Filter RoughScan Portable Surface Roughness Tester Piezo-Electric Probe
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Stability GTS Small and Light Gloss Meter for Car, Electronic, Decoration, Casing
-
High Stability ASTMD523 Aluminum Alloys GT60 Gloss Meter Stable Light for Floor Board, Car
-
ST5900 Handheld Digital Ultrasonic Thickness Gauge for Measure Steel Wall Thickness
-
LCD Display Hartip 2000 Hardness Tester with Universal Angle Bluetooth / RS232 Interface
-
Large memory GM60 Gloss Meter Three-angle With internal Bluetooth, USB interface
-
SM500 Handheld Monocular Microscope 100x - 500x 6V 15W Illuminator Magnetic Stand
Product Details
| Brand Name | SADT | Place of Origin | China | |
| Model Number | ROUGHSCAN |
Product Description
Certification:ＣＥ ＩＳＯ９００１
ANSI 2RC Filter RoughScan Portable Surface Roughness Tester Piezo-Electric Probe
RoughScan is a portable, batterypowered, micro processed instrument for checking surface roughness with
digital readout on LCD. RoughScan can be widely used in laboratory, inspection area in the shop, or wherever
on-suit surface roughness testing is required.
Display: 3-digit LCD
Measuring range: Ra(ISO): 0.03μm-6.3μm/1μ\"-250μ\"? Rz(DIN): 0.2μm-25.0μm/8μ\"-999μ\"
??????????????? ? ? ? ? ? ? ? ? ? ? ?? Ry/Rmax(ISO):0.2μm~250μm/8μ\"~999μ\"
Resolution: 0.01μm/1μ\"
Accuracy: conform ISO and DIN standards
Uncertainty: ≤ 2%
Cut-off(l): 0.8mm/0.30\", ANSI 2RC Filter
Power: 9-volt alkaline battery?? ?
Battery capacity: approx. 3000 measurements
Probe type:piezo-electric
Maximum stylus force: 15.0mN / 1500mgf
Operating temperature: 10°C~45°C / 50°F~113°F
Storage temperature: 0°C~60°C / 32°F~147°F
?
