Packaging Carton Box Making Machine Molding , Die-Cutter Slotter

Packaging Carton Box Making Machine Molding , Die-Cutter Slotter

Material:?Steel

Packaging?Type:?Pallet

Driven?Type:?Electric

Automatic?Grade:?Automatic?

Voltage:380V?50HZ

Power:5KW

Application:?To?make?all?kinds?of?corrugated?carton?box

Main Technical Parameter

Features:

1.This machine is exclusive equipment for die cutting and molding, suitable for the manufacturing of colorful

cartons, boxes and other package products of abnormal shape.

2.It adopts the double roller pressing and urethane soft template; die cutting speed difference servo makes

up the linear velocity automatically, completing the paperboard and the siding, slotting, punching, creasing

and folding of the corrugated paper of medium and small thickness at one time.

3.The machine adopts the vacuum adsorption feeding facility; the main machine adjusts the speed by

electromagnetism and the die cutting phase by computer, featuring high precision of die cutting, high speed

and convenient operation.

Technical Instruction of the Equipment:

1.Die cutter phase is adjusted by computer and electric digital control in a scope of 360o

2.Die cutter horizontal movement is adjusted by computer and electric digital control of a scope of ±5mm.

3.Die cutting cushion roller moves in the automatic and horizontal manner, automatically making up for

linear velocity ensures even wear of the UNFLAIR glue cushion. The equipped cushion repairing system

enables several times of using the cushion, which makes the die cutting and formation beautiful without

damaging knives.

4.The cushion roller’s mechanical, horizontal and cam facility moves horizontally in a scope of ±35mm to

lengthen the using life of the die cutting cushion.

5.The light alloy aluminum back-kick vacuum adsorption feeding system, with several groups of rolling

bearing, ensures stable running.

6.Left and right baffle and back baffle positions are under the computer and electric and digital control as

the side baffle is equipped with pneumatic trimming facilities.

7.Consecutive or skip paper feeding goes with the infrared electrophonic counter.

8.Imported controlling system along with Siemens low voltage electric appliance and host frequency

conversion control realizes the electricity saving about 30%.

Functions of piling unit:

1.The height of stack is 1600mm.

2.The rising and descending of the machine tool platform is driven by the powerful chain. The rising and

descending motor has equipped with the brake function to keep fixed position of the machine tool

unchanged
