3.7V 4400mAh LED Display heated vest Li-ion Battery Packs with smart outputs

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	PoMaX		Place of Origin	China
Model Number	LX-DRF03M

Delivery Time:In 7 days
Certification:CE, FCC, RoHs

3.7V 4400mAh LED Display heated vest Li-ion Battery Packs with smart outputs???????

Parameters

Model No.	LX-DRF03M
Nominal Voltage	3.7v
Working Voltage	3V-4.2V
Nominal Capacity	4400mAh
Charge Cut-off Voltage	4.2v
Charge Current	1A
Standby Current	≤15μA
Max. Output Power	15W MAX
Operating Efficiency	≥99%
Loading Resistance	5Ω-200Ω
Charge Method	CC/CV Constant Current/Constant
Charge Temperature	0℃—40℃
Discharge Temperature	-20℃～ +60℃
Charge Duration	5hrs(Standard)
Cycle Life Time	Above 500 cycles
Internal Impedance	PCB Internal Impedance<80mΩ; Battery Internal Impedance <180mΩ
LED Display	4-heat settings, capacity level indication
Output Terminal	DC3.51.357mm
Usage	For heated vestss, heated seat cushions, etc.
Battery Size	704822mm
Weight	130g
Color	black, white, red, pink, blue, brown, etc.
Certificates	CE, FCC, ROHS
Lead Time for Sample	3~7 days
Lead Time for Bulk Order	7~15 days

Operation:

Power Indication:

Without load, press & hold the black button to check capacity level:

1 LED blinking: Remaining Capacity<=20%

1 LED: Remaining Capacity <=40%

2 LEDs: Remaining Capacity <=60%

3 LEDs: Remaining Capacity <=80%
