3200kg High Capacity Single Cage Hoists with Mast Hot-dip Galvanized
- T/T L/C D/P D/A
- 7 days
You May Like
-
Single Car 300kg Capacity Industrial Elevators CH300 with Mast Hot-dip Galvanized
-
Rack / Pinion Industrial Elevators CH500 Single Car 500kg High Capacity
-
Durable Industrial Elevators For Transport Personnel , Construction Materials
-
1000 kg 2 Double Cage Industrial Elevators with Lifting Height 150 m
-
Heat treatment Rack and Pinion Durable Industrial elevators for construction site
-
Single Car Industrial Elevators , Building Lifter CH160 with 118 Mast Section
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
?
?
Cage Hoist SC 320 Single Cage 3200kg Capacity with Mast Hot-dip Galvanized
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Builder Hoist |
Builder Hoist SC 320 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
3200kg |
Certificate |
CE |
?
?
Description:
?
Builder Hoist SC 320 is installed and dismounted conveniently and can grow as high as the building grows height.The Builder Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
SC serialization of products Builder Hoist is a Rack and Pinion EL. Builder Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of?single cage?:
|
Parameter |
SC100 |
SC160 |
SC200 |
SC270 |
SC320 |
|
Rated |
1000 |
1600 |
2000 |
2700 |
3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12 |
18 |
24 |
30 |
38 |
|
Max. lifting height(m) |
150 |
200 |
450 |
450 |
450 |
|
Engine power(kW) |
2*9.5 |
2*11 |
2*13 |
3*18.5 |
3*22 |
|
Cage?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4? |
