Construction Material Lift Equipment Hoisting Machine for transporting passenger
- 0 Unit / Units per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Single / Double Car 2700kg Industrial Elevators with Mast Hot-dip Galvanized
-
OEM Custom Industrial elevators / Cargo Lift for Construction Material and Passenger
-
CE Approved Professional Iindustrial Elevators and Lifts , Material Hoisting Equipment
-
Frequency Conversion Industrial elevators 3200kg High Capacity for Bridge Engineering
-
Vertical Single Car 300kg Capacity Industrial Lift , Construction Elevator
-
Industrial Rack and Pinion Hoist Construction Material Lift Equipment 500kg
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
0 ~ 60m / min Lifting Speed Industrial elevators With CH 200 Single Cage
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial elevators |
Industrial elevators CH 2000 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2000kg |
Certificate |
CE |
?
?
DeCription:
?
Industrial elevators CH 2000 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial elevators has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
CH serialization of products Industrial elevators is a Rack and Pinion EL. Industrial elevators widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of?single car?:
|
Parameter |
CH1000 |
CH1600 |
CH2000 |
CH2700 |
CH3200 |
|
Rated |
1000 |
1600 |
2000 |
2700 |
3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12 |
18 |
24 |
30 |
38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*9.5 |
2*11 |
2*13 |
3*18.5 |
3*22 |
|
Car?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
