Home > Products > Industrial Water Chiller > 240V - 1N - 50HZ Copeland Compressor Air Cooled Industrial Water Chiller 5.25Kw Cooling Capacity
240V - 1N - 50HZ Copeland Compressor Air Cooled Industrial Water Chiller 5.25Kw Cooling Capacity
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Totally Enclosed Whirlpool Type Water Cooled Air Conditioner Industrial Water Chillers RO-50WK / 3N-
-
High-Efficiency Oil Type PLC Control Mould Temperature Controller RO-060S / 45-180c / 3 N-380V-50HZ
-
Water Type Mould Temperature Controller RO-06D 40 - 100 Temperature Range 6KW Heating Capacity 3N
-
Air Cooled Water Chiller Without Water-Cooling Tower RO-08A Cooling Capacity 21.8KW 3N-380V / 415V -
-
Blue And White Water Type Mold Temperature Controller With Touch Control Panel RO-036D 3N - 380V - 5
-
Closed Water Loop 157.9KW Cooling Capacity Industrial Water Chiller R407C Refrigerant With Sanyo Scr
Product Details
| Brand Name | XHOUG | Place of Origin | China | |
| Model Number | XHOUG |
Product Description
Certification:CE & ISO9001:2000
240V - 1N - 50HZ Copeland Compressor Air Cooled Industrial Water Chiller 5.25Kw Cooling Capacity
Industrial?Chiller
1.Compressor: copeland
2.Heating compoent:electrical heating wire
3.Outlet temperature:-10 degrees
????RIOU?Industrial Chiller is designed of case type, totally-enclosed case shell, and beautiful appearance. It can be placed directly on the working site, keep constant running ever under changeable temperature outdoors and prevent dust from influencing heat elimination. Main machine use compressor of famous brand imported from America and Japan, with safe protection, low noise, energy-saving and durable.
1.Electric control part use famous brand LG which can search failure automatically and display it on the screen at the same time to ensure the machine operate steadily.
?
2.Evaporator ?adopt high-efficiency U type screw tube, with pump inside, clean and maintenance easily and quickly.
???
3.Condenser is consistant by fin type aluminum foil and high-effciency screw tube, with rational design and in good heat exchange effect.
???
4.Only need to connect the pipe with source of water and electricity when installation.
???
5.Low running maintenance charge
???
6.Air cooling assistant water cooling,when this machine is operated
?
?
Model | RO-07AL |
Cooling?Capacity?(Kw/h) | 5.25(-10C?outlet,40C?cond?temp), |
Heating?Capacity(Kw/h) | 3*2(could?work?together?and?separately) |
Total?input?power(kw) | 6.45 |
The?Water?Flow(m3/h) | 3.2 |
Cooling?Air?Volume(?m3/h) | 70000 |
Refrigerant | R404A |
Temp?Outlet?Control(°C) | -10-Normal |
Compressor?Input?Power(KW) | 2.63*2 |
Pump?Input?Power(KW) | 0.75 |
The?water?pipe?size?(G\") | ??1\" |
Water?Tank?Volume(L) | 110 |
Power?Supply | 1N/240V/50HZ |
Dimension(L×W×H)mm | 1320*770*1520 |
Weight(KG) | 320 |
Disposition: |
|
Protective?Device: |
To give you our best offer one time,please indicate:
1.What is the cooling capacity you need?
2.Air cooled or water cooled?As you see,water cooled need a separated cooling tower .
3.What is the outlet water/glycol/seawater temp you need?
4.What is the power supply?
5.Do you need water pump,water tank together?
6.Is there any special requirement for the refrigerant?R22,R134A,R407C,R404A or other?
?
Welcome to contact? vivian@rozl.com!
