Air Cooled Industrial Water Chiller, Water Flow 2.4m3/h RO-05A

? Air Cooled Industrial Water Chiller, Water Flow 2.4m3/h RO-05A

Specifications

Industrial Water Chiller

1,high efficiency

2,semi-hermetic screw compressor

3,R22

4,Water Flow 2.4m3/h

RIOU air cooled chiller use high efficiency semi-hermetic screw compressor
It can realize 4 steps or stepless capacity control. The unique squirrel cage compressor motor started up by Y type can decrease start current by 33%, automatically cooled by the refrigerant.

RIOU air cooled chiller use high efficiency air side heat exchanger
Unique M-shaped design, inner grooved & patent sawtooth design and hydrophilic aluminum fin guarantee efficient heat exchange between the air side exchanger and ambient air.

RIOO air cooled chiller use shell & tube heat exchanger Dry type & tube heat exchanger with inner grooved copper tube optimizes the cooling & heating efficiency. Self-cleaning, high intensity, anti-shaking design and heat insulation covering material ensure shell & tube heat exchanger unstained, reliable, quiet, highly efficient.

RIOU air cooled chiller equipped with complete protection, Water shortage protection, high/low voltage protection, anti-freezing protection, overload protection, overheat protection and oil level protection ensure high reliability and stability.
?

Applied Machinery: Cooling system of oil temperature, ultrasonic, high frequency machinery,injection molding machinery,? blow molding machinery.
?

Cooling Water Flow 2.4m3/h,5degrees Outlet,Air Cooled Industrial Chiller? Model : RO-05A

?Parameters

1,Cooling capacity(kcal/h):11990

2,The Rate Of Cold Water(m3/h):2.4 (plate exchanger evaporator)

3,Compressor Power(KW):3.75

4,The Rate Of Cooling Air(m3/h):5000

5,The Pump Power(KW):0.75

6,Power Supply:3phase-380/415-50/60Hz

7,Refrigeration:R22

8,Dimension L×W×H(mm):1035*610*1365

9,Weight(KG):170

Protective Device?

1,Phase protector

2,Fan overload protector

3,High/low voltage protector

4,Water level protector

5,Anti-freeze protector

To give you our best offer one time,please indicate:
1.What is the cooling capacity you need?
2.Air cooled or water cooled?As you see,water cooled need a separated cooling tower .
3.What is the outlet water/glycol/seawater temp you need?
4.What is the power supply?
5.Do you need water pump,water tank together?
6.Is there any special requirement for the refrigerant?R22,R134A,R407C,R404A or other?
