Home > Products > Innolux LCD Screen > 8 inch LVDS Innolux Tablet LCD Panel 1024x600 ZJ080NA-08A 8
8 inch LVDS Innolux Tablet LCD Panel 1024x600 ZJ080NA-08A 8
- T/T L/C D/P D/A
- 7 days
You May Like
-
1024x600 7 inch touch screen display ZJ070NA-01P for Android Tablet PC
-
Innolux 4.3 inch 480x272 lcd module AT043TN25 V1 for visual doorbell
-
LED Backlight 5\" Innolux LCD screen AT050TN35 / 480x272 LCD Monitor
-
Digital 800x480 Innolux touch panel display for tablet PC AT050TN43
-
RGB vertical stripe Innolux LCD screen 800x480 ED050NA-01C Backlit LED
-
DVD Player 350nits Innolux LCD screen / LCD Monitor 800x600 EE070NA-07A
Product Details
| Brand Name | Innolux | Place of Origin | China | |
| Model Number | ZJ080NA-08A |
Product Description
Certification:CE ,ROHS
8 inch LVDS Innolux Tablet LCD Panel 1024x600 ZJ080NA-08A 8
Quick Detail:
1. Lcd size:8\"
2. Resolution: 1024 × 3(RGB) × 600
3. Brightness: 500nits
4. Weight: TBD
5. Backlight: LED
Applications:
industrial control and car application lcd panel.besides,we have different size lcd panel apply to different fileds. such as tablet pc ,health care, Digital video cameras, digital cameras, portable DVD player, visual doorbell,.
Specifications:
| Screen?Size | 8\" |
| Aspect Ratio | 6:9 |
| Display?Mode | Transmissive |
| Resolution | 1024X3(RGB)X600 |
| PPI?(?Pixel?per?inch?) | 149 |
| Module/Panel?Size(mm) | 192.8×116.9×6.4 |
| Active?Area(mm) | 176.64 × 99.36 |
| Dot?Pitch(mm) | 0.0575(W)X0.1656(H) |
| Viewing?Angle?(Tpy.)θT/θB/θL/θR | 70/75/75/75 |
| Viewing?direction | 6 O\'Clock |
| NTSC | 70% |
| Luminance(nits) | 500 |
| Contrast?Ratio | 700 |
| Response?Time(ms) | 25 |
| Weight?(g) | TBD |
| Interface |
40pin FPC, \'LVDS |
| Operation?Temperature(?℃) | -20~80 |
| Storage?Temperature?(℃) | -30~80 |
| HTHH.(op) | 60℃,90% RH |
Competitive Advantage:
+ we are the agent of AUO/CPT/Innolux in ShenZhen China
+ Secure Ordering
+ Delivery Date Guarantee
+ 100% Low Price Guaranteed
HK SEBO Electronics Co., Ltd. was founded in 2007. Our main products are all kinds of lcd panels. As the agent of AUO/CPT/Innolux,in Shenzhen, China, we have supplied our lcd panels to many lcd monitor, lcd TV, notebook pc, digital photo frame, DVD player, industrial display and car display factories from at home and abroad
With the advantage of our lcd panels, we have been engaged in the R&D of led backlight for lcd panel since the year of 2010 to satisfy customer;s different demand of lcd panel\'s brightness.
