Product Details
| Brand Name | CRT | Place of Origin | China | |
| Model Number | CRT-350 |
Product Description
Security USB Smart Motorized Access Card Reader And Writer , DC 24V?
Quick Detail:
CRT-350 series are motorized card reader and writer which can read/write IC/RFID/Magnetic card.
Description:
Motorized card reader CRT-350 with below main features:
3 in 1:IC/RFID/Magnetic card read/write Hi-Co (2500 Oe-4000 Oe, 2750 Oe the best)& Lo-co(250 Oe-700 Oe, 300 Oe the best) for option Capture card from the front and rear Reject abnormal card and extra long card Two anti-skimming ways: hardware and software Multiple kinds of shutter options Optional components: power-fail protection & PSAM board(4/8bits) Conform to WOSA/XFS 2.0/3.0 and SP provided Optional interface: RS232 & USB(HID) Life time: 1,000,000 times min. Conform to EMV and ROHS standardApplications:
ATM
Payment systems
Kiosk terminals
Access control terminals
Security terminals
Parking systems
Specifications:
|
Card standard |
Magnetic Card: ISO7810 ID-1,7811 |
|
Life time |
Magnetic head:500,000? passes IC card contact:300,000 passes Motor:500,000 passes |
|
Communication |
RS232 interface & USB interface option (HID) |
|
Power supply |
DC24V±5% |
|
Current consumption |
Standby current: 90mA Peak current: 800mA |
|
Temperature/Humidity |
Operation:0~50℃/0 ~ 90%?RH(Non condensing) |
|
Dimension (LxWxH) |
215x124x90mm |
|
Weight |
Approx .1.8kg |
Competitive Advantage:
★?High security design
★?Compatible with other brand’s external dimension and communication protocol
★?PSAM Board for option
★?Reject abnormal card automatically
★?Tamper-Proof Design
★?Hi-co & Lo-co for option, if choose Hi-co, Both Lo-co and Hi-co can be operated. ????
