DMX Laser Lights , 50mW - 500mW RGY / RBP / GBC Laser Party Lights
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Red / Green 50mW - 150mW DMX Laser Lights Stage Light For Bar Show
-
DMX DJ laser lights , 50mW - 150mW RG Stage Laser Lights
-
DMX RG Stage Laser Lights Of 50mW - 150mW Class 3B Laser Lighting
-
MSD 200 W Phillips Sharpy LED Moving Head Beam , DMX Rotating LED Beam
-
Disco LED Moving Head Beam Of Red / Green / Blue / White LED Lighting
-
360Unlimted Rotating LED Moving Head Beam For Bar Show Stage Lighting
Product Details
| Brand Name | Yenlite | Place of Origin | China | |
| Model Number | YL-L007 |
Product Description
Certification:CE, RoHS
DMX Laser Lights , 50mW - 500mW RGY / RBP / GBC Laser Party Lights
Quick Detail:
50mW -500mW? RGY,RBP or GBC Stage Laser Lights YL-L007
Specifications:
|
Model |
YL-L007(RGY) |
YL-L007(RBP) |
YL-L007(GBC) |
|
Red? LD 650nm |
150mw |
150mw |
|
|
Green DPSS 532nm |
50mw |
50mw |
|
|
Bule LD 450nm |
500mw |
500mw |
|
|
Laser level |
Class 3B Laser |
Class 4 Laser |
|
|
Mess |
240x220x110mm |
||
|
Weight |
2.83 kg |
2.91kg |
2.83 kg |
|
Range |
100-240V 50/60Hz |
||
|
Fuse |
250V 1 A Slow Blow (20mm Glass) |
||
|
Consumption |
30W |
||
|
Channel Range |
6 / 9 / 10 |
||
|
AUTO |
Three Show AUTO |
||
|
SOUND |
Three Show SOUND |
Description:
DMX instructions
DMX Channels Chart
Several optional operating modes were preprogrammed set into this laser projector at DMX channel 1. Before control other DMX channels, please be sure that the channel 1 was set in proper mode (value).
|
Channel |
Value |
Function |
|
Ch1 mode |
000-024 |
?Laser |
|
025-049 |
Mixed show Auto.? Pattern + grating |
|
|
050-074 |
Mixed show sound? Pattern + grating |
|
|
075-099 |
Pattern show Auto |
|
|
100-124 |
Pattern show sound |
|
|
125-149 |
Grating show Auto |
|
|
150-174 |
Grating show sound |
|
|
175-199 |
Grating dot show DMX |
|
|
200-224 |
Grating pattern show DMX |
|
|
225-255 |
Original pattern show DMX |
Grating dot show,? number in 175-199 Ch1
|
Channel |
Value |
Function |
|
CH2 X axis mobile |
000-127 |
128 different fixed position on X axis |
|
128-191 |
Clockwise moving |
|
|
128-255 |
Anticlockwise moving |
|
|
CH3 Y axis mobile |
000-127 |
128 different fixed position on Y axis |
|
128-191 |
