Galvanized Steel Floor Deck Tile Making Machine , Metal Deck Roll Forming Machine
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic Metal Sheet Metal Roll Forming Machines For Floor Decking
-
Galvanized Arched Roof / Dome Steel Building Curving Roll Forming Machine
-
Automatic Color Steel Arch Roof Curving Machine / Roll Forming Machine
-
Automatic Plate Straightening Machine Color Steel Sheet Leveling Machine
-
Glazed Sheet Metal Wall Panel Roll Forming Machine / Roof Tile Making Machine
-
Metal Roofing Glazed Tile Roll Forming Machine With 11 Steps Forming Roller
Product Details
| Brand Name | HuaTong | Place of Origin | China | |
| Model Number | HT 688 |
Product Description
Certification:ISO9001：2008
Galvanized Steel Floor Deck Tile Making Machine , Metal Deck Roll Forming Machine
?
?
Quick detail
|
Name |
floor deck roll forming machine |
use |
road |
|
Color |
any |
certification |
ISO9001:2008 |
|
warranty |
1 year |
Line speed |
10M/MIN |
Profile drawing of the production
Production flowing chart of the floor decking roll forming machine
?
Specification
?
?
|
Thickness of middle plate |
20 |
|
Step of roller |
28 |
|
Diameter of shaft |
90mm |
|
Power of main motor |
11kw*2 |
|
Motor power of hydraulic station |
4kw |
|
Line speed |
10m/min |
|
Accuracy of cutting |
2mm |
|
Razor blades material |
?Cr12, quenching 58-62 °. |
|
Size of the machine |
12m (length)*1.5m (width) *1.5m (height) |
|
plc |
DELTA |
|
Frequency converter |
DELTA |
|
After-sales service provide |
?Engineers available to service machinery overseas |
|
Material of frame |
360 I beam |
|
Material of shaft |
(high grade) 45# Steel,quenching and Tempering treatment |
|
Material of roller |
45# steel |
|
Treatment of roller |
Hard chromize coated |
|
Drive type of roll forming machine |
Drive by chain |
|
chain |
38.1mm(high grade) |
|
Bearing |
6210(high grade) |
|
Reducer |
9# cycloid reducer(high grade) |
|
voltage |
380v/50hz/3 phase |
|
Oil pump of hydraulic station |
Gear oil pump(high grade) |
|
Hydraulic cutting |
Cutting controlled by PLC |
|
Effective width |
910mm |
|
Feeding width |
1200mm |
|
Thickness of formed steel |
0.5-1.0mm |
?
Machine components of full line:
(1) Manual un-coiler????????????? ???????????????????1 set
(2) Feeding device?????????????????????????????????? 1 set
(3) Roll-forming M/C??????????????????????????????? 1 set
(4) Hydraulic cutter????????????????? ????????????????1set
(5) PLC control system?????????????????????????????? 1 set
(6) Hydraulic station ????????????????????????????????1 set
(7) Product rack (un-powered)??????????????????????? ?1 set
?
Why to choose our roll forming machine?
We know there are many companies you can choose, and maybe you think our price is higher than others, so I will introduce the different between our products and others. And how to choose the good machine. A
