Phenolic / Titanium Compression Driver Tweeter , 1 inch Throat

Phenolic / Titanium Compression Driver Tweeter , 1 in Throat

8ohm CY-2542S Compression Driver Tweeter Driver

Description:

1)Power Capacity:30W RMS
2)Sensitivity:110dB
3)Audio,HF,Speaker Driver
4)Impedance:8Ohm,0.78 KG
5)1.5KHz-20KHz Freq

Specifications:

Throat Diameter : 1 in (25mm)
Mounting Type : Screw on 1 3/8″
Nominal Impedance : 8 Ohm
Power Capacity : 30Watts RMS
Sensitivity(1W/1M) : 110dB
Frequency Range : 1.5KHz-20KHz
Diaphragm Material : Phenolic or Titanium
Voice Coil Diameter : 1 in(25.4mm)
Voice Coil Material : Round&Ribbon Aluminium Wire
Flux Density : 1.7T
Magnet : Strontium Ferrite
Overall Diameter×Depth : 80mm (3.15in)×68.5mm (2.7in)
Net Weight : 0.78Kg

Overview:

High quality compression driver offering excellent efficiency and low distortion. It is recommended for use in studio monitors, stage boxes, and sound reinforcement in small to medium rooms.

Highlights:

Titanium diaphragm for durability and extended HF response

Optimized phase plug eliminate phase cancellation problems

High-temperature voice coil materials ensure reliability

Smooth, extended frequency response

Easy diaphragm replacement
