Studio Monitor Compression Driver Tweeter ,80W RMS 1 in Throat

Studio Monitor Compression Driver Tweeter ,80W RMS 1 in Throat

8ohm CY-5161S Compression Driver Tweeter Driver

Description:

1)Power Capacity:80W RMS
2)Sensitivity:112dB
3)Tweeter,Audio,Compression Driver
4)Impedance:8Ohm,
5)1.0KHz-20KHz

Specifications:

Throat Diameter : 1 in (25mm)
Mounting Type : Screw on 1 3/8″or Bolt-on
Nominal Impedance : 8 Ohm
Power Capacity : 80Watts RMS
Sensitivity (1W/1M) :112dB
Frequency Range : 1.0KHz-20KHz
Diaphragm Material : Titanium
Voice Coil Diameter : 2.03 in(51.6mm)
Voice Coil Material : Round&Ribbon Aluminium Wire
Flux Density : 1.75T
Magnet : Strontium Ferrite
Overall Diameter×Depth : 134mm (5.28in)×79.5mm (3.13in)
Net Weight : 2.83Kg

Overview:

High quality compression driver offering excellent efficiency and low distortion. It is recommended for use in studio monitors, stage boxes, and sound reinforcement in small to medium rooms.

Highlights:

Titanium diaphragm for durability and extended HF response

Optimized phase plug eliminate phase cancellation problems

High-temperature voice coil materials ensure reliability

Smooth, extended frequency response

Easy diaphragm replacement
