Curved Thermal Insulated Glass For Building , Sound Insulation

Curved Thermal Insulated Glass For Building , Sound Insulation

Description:

Insulated glass is made of two or more than two sheets of glass with space partitioned by aluminum frame filled with high efficiently hasten drying agent. The edge of insulated glass is sealed by high strength sealing sealants.??
?

Features:

1. Energy Saving: For the low heat conductibility of the sealed air between the glass, the insulated glass can reduce heat transfer from inside to outside. Therefore, it can save energy by 30%-50%.?

2. Sound Insulation Performance: Single layer glass can reduce noise to 20-22dB. Normal insulated glass can reduce noise to 29-31 while special insulated glass to 45dB.?

3. Anti-dew: Insulated glass is filled enough desiccant which can efficiently absorb vapor in the inner space or penetrated from outside to ensure the gas in inner space is absolutely dry and won\'t dew.?

Application:

Glass curtain wall and light absorption shade of residential area, hospital, office building, shopping mall, hotel and library and other places that need keeping warm, saving energy and keeping silent.?

Specification:?

According to customers\' requirements?
Aluminum Frame thickness: 6mm, 9mm, 12mm 15mm?
Thickness of glass: 3-25mm?

Quality:?

AS/NZS 2208:1996 Safety glazing materials in buildings
In accordance with CE certificate EN1279-1:2004 EN1279-5:2005
In accordance with GB/T 11944-2002 Chinese Insulating Glass Standard

Pass Chinese Safety Glass Compulsory Certification (CCC)
