Cort transmission industrial Planetary Gearbox motor speed reducer

CORT transmission industrial Planetary Gearbox motor speed reducer

Quick Details:

Other name:

CORT industrial robot arm gearbox

CORT transmission gear reducer

CORT compound oscillatory Roller transmission reducer

Descriptions:

CORT transmission industrial Planetary Gearbox?is based on the drive of oscillatory transmission, a series

gear branch input multi-synchronous input shaft roller power transmission to ensure that it covers a high-

precision drive, high?stiffness, high load characteristics. The products were patents, patent

No.:97100463.3?Because of its superior performance, roll tooth drive can be widely used in petrochemical,

metallurgical?mine, light pharmaceutical, food oil, textile printing and dyeing, overweight, such as

transportation and?construction machinery industry machinery used for deceleration. If necessary, it can

also be used with the growth rate, It is worth mentioning that the roll transmission gear has extremely

carrying capacity, can?achieve high-precision, high-stiffness compound rolling live transmission gear was

developed and patents?for invention was accessed. Such precision reducer is particularly applicable to

robots, CNC equipment,?aerospace equipment, defense equipment and weapons requirements of high-

precision control of the?transmission system.

Performance characteristics:

1. Multi-tooth meshing-High load capacity

2. Simple Structure. No indispensable output institutions as in cycloid reducer

3. High-speed motor can be connected to drive, and this would be benefit to the requirement of sensitivity

of intelligent control system

4. Basically can achieve rolling meshing, transmission with high efficiency. CORT reducer normally be used

in the speed ratio of (i=40~180),the mechanical efficiency of 80-90%

5. Bigger transmission ratio, compact structure

6. Big output rigidity, slight backlash

7. When do transmission, torque fluctuations less.

Specifications:
