Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow Moulding Machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
2L semi automatic Bottle Blowing Machine 1600BPH in Stretch Blow Moulding
-
PET Bottle Blowing Machine , 2000BPH Auto Blowing Molding Machine 220V
-
Automatic water bottle Bottle Blowing Machine 4000BPH with CE Approvals
-
Three in One liquid filling machine , bonated drink filling plant for Gas beverage 110V
-
Carbonated drink Glass Bottle Filling Machine , Auto Filling Line for beverage
-
PET Bottle liquid bottle filling machine , Electric Filling Equipment
Product Details
| Brand Name | Renda | Place of Origin | China | |
| Model Number | CM-8Y |
Product Description
Certification:ISO,CE
Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow Moulding Machine
Quick Detail:
Condition: New Application: Bottle Plastic Processed: PET Blow Moulding Type: Stretch Blow Moulding Automatic: Yes Model Number: CM-8YDescription:
1. Solenoid Valve (Pneumatic Valve for Mold Clamping): Korea, PMC
2. High Pressure Valve (Blowing Valve): China
3. Seal & Stretch Cylinder: China
4. Clamping Cylinder: China
5. PLC: Delta, Taiwan
Applications:
CM-8Y Semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 0.1L to 2L.
Specifications:
|
Model |
ITEM |
CM-8Y |
|
|
Container |
Product material |
/ |
PET |
|
Volume |
L |
0.1-2 |
|
|
Theoretical output |
pcs/h |
1400-1800 |
|
|
Preform length |
mm |
≤350 |
|
|
Preform inner diameter |
mm |
φ5-38 |
|
|
Mould |
Max.mould plate Diameter(L*W) |
mm |
350*380 |
|
Max.mould thickness |
mm |
180 |
|
|
Clamping force |
kn |
45 |
|
|
Mould opening stroke |
mm |
160 |
|
|
Machine size and Weight |
Main machine (L*W*H) |
cm |
1600*600*1610 |
|
Main machine weight |
kg |
500 |
|
|
Heater (L* W*H) |
cm |
1870*630*1450 |
|
|
Heater weight |
kg |
250 |
|
|
Power |
kw |
17.5 |
Competitive Advantage:
Save Cost Stable Quality Save PlaceContact Us
