Home > Products > Impact Extrusion Press > Vertical Frame Type Cold Extrusion Press For Aluminum / Iron / Zinc Cans
Vertical Frame Type Cold Extrusion Press For Aluminum / Iron / Zinc Cans
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Aluminum Tube / Can Impact Extrusion Press Equipments For Automobile Filters
-
Frame Type Cold Extrusion Press Equipment For Aluminum / Iron / Zinc Tube
-
High Speed Horizontal Mechanic Cold Extrusion Press for Aluminum, Iron and Zinc tube
-
Hydraulic Impact Cold Extrusion Press For Automobile Filters
-
Horizontal High Speed Impact Extrusion Machine For Extinguisher
-
High Speed Vertical Cold Extrusion Press 5.5 kw 20mm 50mm 55mm
Product Details
| Brand Name | WKH | Place of Origin | China | |
| Model Number | N/A |
Product Description
Certification:ISO9001:2000
Specification of Horizontal extrusion press:
|
Item |
Unit |
60A |
60B |
180 |
200B |
200C |
200K |
|
Nominal pressure |
KN |
600 |
600 |
1800 |
2000 |
2000 |
2000 |
|
Nominal pressure stroke |
mm |
5 |
5 |
5 |
5 |
5 |
5 |
|
Stroke of slide |
mm |
220 |
145 |
250 |
300 |
190 |
155 |
|
Stroke per minute |
Min-1 |
60 |
100 |
65 |
65 |
85 |
100 |
|
Max shut height |
mm |
355 |
355 |
460 |
480 |
480 |
480 |
|
Adjustment of shut height |
mm |
5 |
5 |
12 |
12 |
12 |
12 |
|
Max diameter of can |
mm |
Φ25 |
Φ20 |
Φ48 |
Φ55 |
Φ50 |
Φ45 |
|
Max length of can |
mm |
130 |
90 |
170 |
200 |
110 |
100 |
|
Power of main motor |
KW |
5.5 |
5.5 |
11 |
11 |
11 |
11 |
|
Item |
Unit |
265 |
315A |
315B |
|
Nominal pressure |
KN |
2650 |
3150 |
3150 |
|
Nominal pressure stroke |
mm |
8 |
10 |
10 |
|
Stroke of slide |
mm |
342 |
385 |
270 |
|
Stroke per minute |
Min-1 |
58 |
48 |
80 |
|
Max shut height |
