Electric CNC Precision Hydraulic Wheel Press Equipment 3-30mm/s

Item

Parameter

Pressure head cylinder max. work pressure???????????????

3150KN

Pressure head cylinder quantity

2

Pressure head cylinder ram cylinder max. stroke???? ????????????????

700 mm

Pressure head cylinder diameter

?360 mm

Gantry max. pass wheel diameter

1050mm

Max insert length

3000 mm

Movable equipment positioning adjustable distance

13x200 mm

Pressure head cylinder plunger rod feeding speed (adjustable)

3~30mm/s

Pressure head cylinder plunger rod push mounting speed (adjustable)

0~3mm/s

Pressure head cylinder plunger rod return speed (adjustable)

4~40mm/s

Two centers max. bearing??????

10000kg

Electricity motive small car quantity

1set

Electricity motive small car max. hold up weight

3500kg

Electricity motive small car rotation angle

180degree

Hydraulic system max. working pressure

31.5Mpa

Motor (three phases) voltage

380V-50HZ

Boost voltage

DC 24V

Installed gross capacity

50KW

Pressure sensor accuracy

≤0.15%FS

Noise level when running

75db

Pressure head measurement inside control precision

≤0.5 mm

Pressure head measurement wheel order difference control precision

≤0.5 mm

Brake disc? distance control precision

≤0.5 mm

Brake disc difference control precision

≤0.5 mm

Pressure head repeated positioning accuracy

≤+0.025 mm

Measurement accuracy

≤+0.03 mm

Measurement error precision (Jump)

±0.02 mm

Measuring system precision

0.01

Pre-press fitting pressure

≤50kN

Oil tank capacity

1000L

Machine external dimension(L×W×H)

6000×2500×2000 mm
