Industrial 3 phase stepper motor 86BYGH with high torque 60kg.cm
- T/T L/C D/P D/A
- 7 days
You May Like
-
CNC 3 phase stepper motor Hybrid 1.2 NEMA 23 57BYGH
-
Round Three phase stepper motor high speed 1.2 degree for Cnc router
-
Industrial 3 phase stepper motor 130mm NEMA 52 with High torque
-
Hybrid 3 phase stepper motor Nema 42 110mm 220v for printer 110BYGH
-
Electronic 3 phase step motors high torque NEMA 42 110BYGH 1.2 Degree
-
Electronic 5 phase stepper motor 110mm 12 N.m- 25 N.m for printer 110BYGH
Product Details
| Brand Name | JK | Place of Origin | China | |
| Model Number | JK86H3P |
Product Description
Certification:CE,ROHS ,ISO9001
Industrial 3 phase stepper motor 86BYGH? with high torque 60kg.cm
?? Nema 34 Hybrid Stepper Motor ??? Model Number: JK86H3P ??? Phase: 3 Phase ??? Structure: Hybrid ??? Step Angle:? 1.2° ??? Motor Height:86mm ??? Holding Torque: 2 N.m - 7N.m ??? Function: Control ??? Speed: Low or High speed ??? Usage: Industrial ??? Shape: Square ? ??? Applications:Use for robots stepper motor, electronic automatic equipment stepping motor , medical instrument stepping motor,advertisementing instrument stepper motor, lighting& audio equipment stepper motor ,printer stepper motor, textile machinery stepper motor.Cnc router stepper motor?1.2°86mm 3phase Square hybrid stepper motor? NEMA34/ 86BYG350 step motor/ 1.5N.M stepping motor/0.9N.m step motor
Description:
NEMA34 stepping motor , 86mm 3 Phase square stepper motor .
45kg.cm Stepper motor , high torque stepper motor with 86mm size .
60kg.cm stepping motor,
Applications:
Use for robots stepper motor, electronic automatic equipment stepping motor , medical instrument stepping motor,advertisementing instrument stepper motor, lighting& audio equipment stepper motor , printer stepper motor, textile machinery stepper motor.
Cnc router stepper motor.
Specifications:
|
Model No. |
Step Angle |
Motor Length |
Current /Phase |
Resistance /Phase |
Inductance /Phase |
Holding Torque |
Rotor Inertia |
Mass |
|
( °) |
(L)mm |
A |
Ω |
mH |
N.m |
g.cm2 |
Kg |
|
|
JK86H3P65-3006 |
1.2 |
65 |
3 |
0.5 |
1.6 |
2 |
1100 |
1.65 |
|
JK86H3P98-5206 |
1.2 |
98 |
5.2 |
0.6 |
3 |
4.5 |
2320 |
2.70 |
|
JK86H3P113-5206 |
1.2 |
113 |
5.2 |
0.9 |
5.9 |
6 |
3100 |
3.50 |
|
JK86H3P150-5006 |
1.2 |
150 |
5.0 |
1.5 |
3 |
7 |
4650 |
5.10 |
Dimensions:
(Unit=mm)
Wiring Diagram:
Matching Stepper motor Driver: JK3M860
