Full-duplex Mode IEEE802.3z/AB Fiber Optic Components Media Converters With SFP Port

Full-duplex Mode IEEE802.3z/AB Fiber Optic Components Media Converters With SFP Port

1．Overview
IEEE802.3z/AB 1000Mbps Gigabit Ethernet supports two types media for network connection such as 10/100/1000Base-T and 1000Base-SX/LX. The media converter is designed with a switch controller and buffer memory that connects two types segments to operate smoothly. With internal power unit, it provides good stability and reliability.

2.Checklist
Before you installing the Converter, verify that the package contains the following:
1).The TP-Fiber Media converter.
2).AC Power Cord.
3).This User’s Manual.
Piease notify your sales representative immediately if any of the aforementioned items is missing or damaged.

3. LED Description

There are six LED At Front View of Gigabit
SFP Converter

4.Installing the Converter

1).Attach a SFP to SFP Cage on the converter
2).Attach fiber cable from the Converter to the fiber network.. The fiber connections must be matched: transmit socket to receive socket.
3).Attach a UTP cable from the TP network device to the RJ45 port on the Converter.
4).Connect the power cord to the Converter and check that the Power LED lights up. The TP Act and FX Act LEDs will light when all the cable connections satisfactory.

?

5.Technical Specifications

?The Converter conforms to the following standards:
Standerds: IEEE 802.3z/AB 10/1001000Base-T??? ?
?? ???????????????? 1000Base-SX/LX
UTP Cable: Cat.5e orCat.6 cable and up to 100m.
Fiber Cable:
?? ?1000SX: 50/125,62.5/125μm molti-mode
?? ?1000LX: 9/125μm single-mode.
Data Transfer Rate:
?? ?2000Mbps for full-duplex at 1000Mbps speed.
LED Indicators:
?? ?TP Act, Fdx, 100, 1000 , Power,? FX Act
TP Flow Control: NWay auto-negotiation
Fiber Flow Control: NWay at full-duplex mode
Power Requirement: 220V(175-260V)AC,50Hz
Ambient Temperature: 0 ～ 50℃
Humidity: 5% ～ 90%
dimensions:Internal:26×70×93mm
External Power: 40×1100×140mm(H×W×D)
