XLPE Insulated Electrical Power Cable Low-voltage
- T/T L/C D/P D/A
- 7 days
You May Like
-
PVC Insulated Fixed Laying Low-voltage Power Cable with Excellent Thermal Stability
-
PVC fiber & mica compound insulated fire-proof soft wire, Fire Proof Cable
-
XLPE fiber & mica compound Fire Proof Cable Application To Chemical Industry, Metallurgy
-
PE fiber & mica compound insulated fire-proof mine signal(soft) cable, Fire Proof Cable
-
PVC fiber & mica compound insulated fire-proof wire Fire Proof Cable
-
XLPE or saline XLPE fiber & mica compound insulated Fire Proof Cable
Product Details
| Brand Name | New Baofeng | Place of Origin | China | |
Product Description
XLPE Insulated Electrical Power Cable Low-voltage
Quick?Detail:
1)Insulation?Material:? XLPE?
?2)?voltage?rating:? low?voltage?
3)?Application:?Industrial,power?station,?underground,?industry
?
GB/T12706.1-2002, equivalent to IEC60502
UsageThis product is suitable for use in rated AC voltage (U0/U) 0.6/1kV system transmitting and distributing circuit.
Property for UseIt is far better than all property targets of PVC insulated power cable and has overcome
the shortcomings of physical and chemical cross-linkage, and completely reaches or surpasses
GB and IEC technical property value.
The allowed max .cable conductor work temperature is 90℃;urgent excess work temperature is
130℃ for short circuit(5s), max. conductor temperature is 250℃.
The environmental temperature for laying cable should be not less than 0℃. If laying under 0℃,
the cable should be preheated.
The cable bend radius for single core should be not less than 12 times of overall cable diameter;
for multi-core cable, not less than 10 times of overall cable diameter.
The current-carrying capacity is large and not limited by drop during laying .
Type of cable|
Type |
Designation |
Application |
|
YJV |
Copper conductor , XLPE insulated and PVC sheathed Electrical cable |
For laying indoors, in tunnels or cable trench, unable to bear external mechanical forces. |
|
YJLV |
Aluminum conductor , XLPE insulated and PVC sheathed Electrical cable |
|
|
YJY |
Copper conductor , XLPE insulated and PE sheathed Electrical cable |
|
|
YJLY |
Aluminum conductor , XLPE insulated and PE sheathed Electrical cable |
|
|
YJV22 |
Copper conductor , XLPE insulated, steel tape armored and PVC sheathed Electrical cable |
Indoors, tunnels, cable canal, vertically burying and easy to corrode places, can bear mechanical pressure. |
|
YJLV22 |
Aluminum conductor , XLPE insulated, steel tape armored and PVC sheathed Electrical cable |
|
|
YJV23 |
Copper conductor , XLPE insulated, steel tape armored and PE sheathed Electrical cable |
|
|
YJLV23 |
Aluminum conductor , XLPE insulated, steel tape armored and PE sheathed Electrical cable |
|
|
YJV32 |
Copper conductor , XLPE insulated, steel wire armored and PVC sheathed Electrical cable |
Vertically laying, can bear mechanical pulling force, but not pressure. |
|
YJLV32 |
Aluminum conductor , XLPE insulated, steel wire armored and PVC sheathed Electrical cable |
|
|
YJV33 |
Copper conductor , XLPE insulated, steel wire armored and PE sheathed Electrical cable |
|
|
YJLV33 |
Aluminum conductor , XLPE insulated, steel wire armored and PE sheathed Electrical cable |
|
Type |
No. of cores |
Nominal cross-sectional area mm2 |
|
|
Copper Conductor |
Aluminum Conductor |
||
|
YJV YJY — YJV22 YJV23 |
— YJLV YJLY YJLV22 YJLV23 |
1* |
