1.5KW - 55KW Sodium Hydroxide Pump , Chemical Resistant Electric Motor Pump

1.5KW - 55KW Sodium Hydroxide Pump , Chemical Resistant Electric Motor Pump

IHF fluorine plastic chemical pumps centrifugal pumps set a variety of advantages, because of its metal casing pump fluorine plastic significantly enhanced mechanical strength and pressure of the pump, using the structure after the door, one can easily carry out routine maintenance inside and component replacement, without dismantling the pump export pipeline. Actual use show that the pump has low noise, corrosion, wear, high mechanical strength, smooth operation, advanced and reasonable structure, reliable sealing, demolition of easy maintenance, long life.Sinofine Fluoplastic IHF centrifugal pump is single-stage and single-suction cantilever-type centrifugal pump. Its label, rate and size meet with the international standard of ISO2858.The pump metal casing fluorine plastics, impeller and pump cover over-current components such as metal inserts are outsourcing a one-time high fluorine plastic alloy molding.

Sinofine Fluoroplastic IHF fluorine plastic centrifugal pump with the current most advanced exterior-type PTFE bellows mechanical seal, which is characterized by radial pump shaft can be compensated, single seal exterior style, easy handling, work status intuitive, corrosion resistant sealing good, with multiple layers of protection, extended mechanical seal life; for particle transport medium containing impurities, can be equipped with cooling water without a single face hard on the hard (silicon carbide on silicon carbide) mechanical seals, alkali and hydrofluoric acid, etc. Special corrosive medium with SiC seal with no pressure, so users need to take into account when the selection medium solids.IHF fluorine plastic centrifugal pump corrosion and wear resistance has been confirmed by the actual use and users of the same recognition has been widely used: chemical production in the corrosive medium transport, ionic membrane caustic soda project in chlorinated water acid treatment and processing technology, non-ferrous metal smelting in electrolyte transport, car manufacturing in the pickling process, and pharmaceuticals, petroleum, electroplating, dyes, pesticides, paper and food industry, in the temperature of -20 °C ~ 100 °C Conveying under any long-term concentration of sulfuric acid, hydrochloric acid, hydrofluoric acid, nitric acid, aqua regia, alkali, strong oxidizing agents and other strong corrosive medium and not damaged, is the most popular use of units of pumping equipment.

Model meaning:

IHF100-80-160

IH - International standard chemical industry centrifugal pump

100 - Inlet Diameter(mm)

80 - Outlet diameter(mm)

160 - Norminal diameter of the impeller(mm)
