8 Ton 180m jib TCP6015-8 China Flat Top Tower Crane Manufacturer For Construction

We are professional manufacturer of tower crane and mast section in China, we also accept OEM and ODM order.

1. Flat top tower crane with convenient installation and disassembly, it is very suitable for crossing tower crane groups.

2. Mast section dimension:1,800mmX1,800mmX2,800mm or 1835mmX1835mmX2500mm,or plate standard section of 2,000mmX2,000mmX3,000mm.

3. The longest jib is 60m,  the  jib combination  decreases progressively 5 meters each and the minimum jib length is 40m.

4. The maximum hoisting capacity is 8 tons.

5. The maximum lifting capacity at a distance of 60m is 1.5 ton.

6. The maximum hoisting moment is 135t.m.

7. The maximum independent height is 59m and the maximum attached height is 180m.

8. Hoisting mechanism: Adopting a variable frequency motor   30KW . Slew mechanism: Adopting a torque motor   3.7 KWX2. Luffing mechanism: Adopting a variable frequency motor    3.3KW.

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

Description:

Our main products are:

Hammer head tower crane QTZ63(TC5013), QTZ80(TC5610, TC5610A,TC 6010, TC6010A), QTZ100(TC6013-6, TC6013A-6, TC6013-8, TC6013A-8), QTZ125(TC6015-8,TC6512-10,), QTZ160(TC7013-10, TC7013-12), QTZ250(TC7520-12, TC7520-16)

Flat head tower crane QTZ125(TCP6015-8, TCP6512-10), QTZ160(TCP7013-10, TCP7013-12)
