TC5013-6 Fixed Tower Crane Q345B Steel For Bridges 40m Lifting Height

We are professional manufacturer of Tower Crane and Mast Section in China, we also accept OEM order and package.

1. Model: TC5013-6(QTZ63)

2. Dimensions: standard section 1,600mmX1,600mmX3,000mm

3. Material: All main chord be made of  Q345B steel

4. Parameter: Max. hoisting load: 6 tons.Tip load:1.3 tons.Max jib length 50m. Free standing height :40m.  Maximum ancorages height :140m

Quick details:

1. The crane is an outside climbing and self-elevating type with horizontal jib, trolley-travelling and upper slewing.

2. The maximum jib length is 50m, the jib combination decreases progressively 6m each and the minimum jib length is 38m.

3. The maximum load is 6 tons.

4. The maximum tip load is 1.3 tons.

5. The maximum load moment is 83.5t.m.

6. The maximum free height is 40m and the maximum ancorages height is 140m.

7. The hoisting mechanism used a three-speed motor and the power is 24KW.

    The slewing mechanism used a double winding motor and the power is 2.2 KWX2.

    The trollrying mechanism used a double-speed motor and the power is 3.3KW.

8. The mast  standard section of 1,600mmX1,600mmX2,800mm or plate standard section of 1,600mmX1,600mmX3,000mm.

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type.

Description:

Our main products are:

Topkit tower crane QTZ63(TC5013), QTZ80(TC5610, TC5610A,TC6010,TC6010A), QTZ100(TC6013-6, TC6013A-6, TC6013-8, TC6013A-8), QTZ125(TC6015-8, TC6015A-8, TC6512-10, TC6512A-10), QTZ160(TC7013-10, TC7013-12), QTZ250(TC7520-12, TC7520-16)

Topless tower crane QTZ125(TCP6015-8, TCP6512-10), QTZ160(TCP7013-10, TCP7013-12)

TC5013(QTZ63) tower crane have fixed, attached types, which are suitable for use in project construction in such industries as water conservancy and hydropower, metallurgy, petroleum, chemical, thermal power, etc., suitable for use in modern industry and civil building construction .
