10 Tons China Building Tower Crane 180m For Construction Bridges

We are the professional manufacturer of tower crane and mast section in China, we also accept OEM and ODM order.

1. Model#: TC6512-10(QTZ125)

2. Dimensions of Mast: 2,000mmX2,000mmX3,000mm

3. Material: All main chord be made of  Q345B steel

4. Parameter: Maximum hoisting capacity is 10 tons, the longest jib is 65m, maximum independent lifting height is 53m, maximum attached height is 180m.

Quick Detail:

1. Mast standard section: 1,800mmX1,800mmX2,800mm , 1835mmX1835mmX2500mm,

    Plate standard section of 2,000mmX2,000mmX3,000mm.

2. The longest jib is 65m,the jib combination decreases progressively 5m each, and the minimum arm length is 45m.

3. The maximum hoisting capacity is 10 tons.

4. The maximum lifting capacity at a distance of 65m is 1.2ton.

5. The maximum hoisting moment is 156t.m.

6. The maximum independent height is 53m and the maximum attached height is 180m.

7. Hoisting mechanism: Adopting a double-speed winding motor   37KW .

8. Slew mechanism: Adopting a double gyration winding motor  5.5 KWX2. Hoisting mechanism: Adopting a three-speed winding motor   5KW .

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

 Our main products are:

Hammer head tower crane  QTZ63(TC5013),QTZ80(TC5610,TC5610A,TC6010TC,TC6010A)QTZ100(TC6013-6,TC6013A-6,TC6013-8,TC6013A-8)QTZ125(TC6015-8,TC6015A-8,TC6512-10,TC6512A-10)QTZ160(TC7013-10,TC7013-12)QTZ250(TC7520-12,TC7520-16)

Flat head tower crane QTZ125(TCP6015-8,TCP6512-10)QTZ160(TCP7013-10,TCP7013-12)

TC6512-10(QTZ125)  Splite mast section which can be exchanged with POTAIN' one.
