1440 DPI Two Side Large Format Eco Solvent Printer / 1.5 - 21 pl Ink Droplet

Type: flex banner printer

Brand Name: A-Starjet

Place of Origin: Changzhou

Automatic Grade: Automatic

Usage: digital double sides vinyl printer

Certification: CE

Voltage: AC 100-120V or 220-240V

Model: 77802L

Weight: 795 kgs

Color: 4 colors / 8 colors

Keyword: Double sides printer

After-sales Service: Yes

Item

A-Starjet 77802L

A-Starjet 77802

Print Head

Two DX7 Drop-on-demande Micro-Piezo Print Heads

Number of nozzles

2880 Nozzles (2 Heads)

Color

4 Colors:Cyan, Megenta, Yellow, Black?????????

8 Colors: Custom Defined (TBE)??????

Resolution

1440dpi(max)

Height of print head

2-5mm

Size of ink droplet

1.5-21pl

Printing width

3200mm

1800mm

Media width

3300mm(max)

1900mm(max)

Real Time Tracking

4 Cameras

3 Cameras

Speed

2 pass: 52 sqm/h/side??

2 pass: 49 sqm/h/side

4 pass: 28 sqm/h/side

4 pass: 25 sqm/h/side

Media take up

Feeder/Take-up System

Yes

Media feeder

Detachable Caster

Yes

Media payload

200kgs(max)

70kgs(max)

Heating system

3-section heaters with PID temperature control

Ink

T5.5 eco-solvent ink

Ink cartridge

8 Cartridges

RIP software RIP

iPrint 3.0(Optional Photoprint, Wasatch)

Control software

iPrint Console(installment versions as option)

Operation system

MS Windows XP & Windows 7

Interface

USB port ver2.0

Power voltage

110-220V or 220-240VAC, 50-60Hz

Printing environment

Temperature: 20-26℃, Humidity: RH40-60%

Printer dimension

W4300*D900*H1250mm

W2840*D900*H1250mm

Packing dimension

W4450*D1450*H1180mm

W2920*D930*H730mm
