DIP346 1R1G1B Virtual full color 16bits Outdoor LED Screen Pixels pitch 20mm high stability

DIP346 1R1G1B Virtual full color 16bits Outdoor LED Screen Pixels pitch 20mm high stability Specifications Outdoor LED Screen
1.Lifespan:100000hours
2.Brightness:5000cd/sq.m
3.Lead time:15 working days
4.screen waterproof:IP65
?

Applications requirements:

Outdoor all-weather environment and rental use. High brightness, high protection rating and high stability.

Characteristics:

General Module which will make the display very flat and minimum gap between modules endow your LED display with an high-end products.

1. Special design which can make our LED panel both front and rear side maintainance accessible. This will greatly cut down the maintain cost.
2. Ultra high brightness (12000 Nit) with low power consumption (300W/M2).?
3. High refresh rate (greater than 3840 Hz) with software adjustable, suitable for filming.?
4. High grayscale (15 bits) with perfect visual performance.?
5. High Contras ratio (2000:1) with black mask and black coating technique.
6. Wide viewing angle (greater than 140 °in horizontal).?
7. IP65 protection rating.?
8. Fast and easy to assemble and dismantle.?
9. High reliability and long lifespan (MTBF ≥ 5000 hours).

Optional for upgrade:

1. Ultra-High refresh rate (greater than 6000 Hz) with software adjustable, suitable for filming.?
2. High grayscale (16bits) with realistic visual performance.?
3. On-site pixel by pixel brightness and color correction bring greater uniformity.

?

Module Specification

Item	Specification?Parameter
Pixel?type	Virtual?full?color
Pixel?color	1R1G1B
Module?size	320*320mm
Pixel?led	DIP346
Pixels?pitch	20mm
Resolution?rate	16*16
Driving?way	Constant?current?drive
Driving?IC	MBI5020
Working?voltage	DC5V
Power	40W
Working?temperature	-30°C?-?+50°C

Screen Specification

Item	Specification
Material	Aluminum?
Color	Black
Size	960*960mm
Resolution?rate	48*48
Module?quantity	3*3
Density	2500dots/m2
White?balance?luminance	≥9000CD/m2
Color?temperature	6500K——8000K
Horizontal?view?angel	110
Vertical?view?angel	50
Protection?grade	?Before/after:?IP67/IP65
Non-Flatness	<1mm
Module?interval
