Digital Design 1KVA double conversion high frequency online ups 50 / 60Hz for Networking

FOB Price

Negotiable / Carton

1 Carton(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Jendia/OEM

Place of Origin

China

Product Description

Delivery Time:15-20days
Certification:CE,ISO9001
Digital Design 1KVA double conversion high frequency online ups 50 / 60Hz for Networking ? Quick Details

Place of Origin:	?China (Mainland)	Brand Name:	OEM	Model Number:	C1K
Phase:	Single Phase	Protection:	overvoltage/short circuit/overload	Weight:	12KG
Output Voltage:	110VAC/220VAC	Type:	On-line	Application:	Networking, telecommunication and so on
Panel:	LED panel	Backup time:	10-15 mintues	Input voltage:	115-300VAC
Power wave:	Sinewave

Specifications

online UPS:
1. Digital Design
2. Reversed Polarity N and L wire Detection Function
3. A Real Green-environmental Protection

1. Digital Design

2. Reversed Polarity N and L wire Detection Function.

3. A Real Green-environmental Protection Power.

4. Direct Current Cold Start Function????

5. Alarm High-low Battery Input Voltage Protection Function

6. Communication and Monitoring Function

7. Output High- Low Voltage Protection

8. Output? Short Circuit Protection

9. Overloaded Protection Function

10. Over-temperature Protection

11. Intelligent Fan Speed Control Function

According to load capability and environmental temperature

Applications:

Work stations & Networks?

Automatic Control Systems?

Automatic and Medical equipment?

Laboratory and Medical equipment?

Security and Emergency Systems?

Banking and Data Processing?

Computer and Communications

model Specifications?and?parameters????????	C1K
Rated?power	1KVA/800W
AC??Input	Input?system	Single?phrase?&?earth?ground
?	Ranged?voltage	208/220/230/240Vac
?	Frequency	50/60Hz
?	Voltage??range	115~300VAC±5
?	Frequency?range	50/60±5Hz
?	Voltage?range?of?bypass	80VAC×(1±5%)285VAC×(1±5%)
Battery??	Voltage?range?of?battery	36VDC
?
Input
?	Battery?capacity*Quantity	12VDC*3
?	Backup?Time?(half/full?loaded)	Half?loaded≥10minutes, Full?loaded?≥5minutes(standard)
?	Transient?rush?current?in?boot-up?state	<150%?of?rated?current
?	Battery?charger?time	Charger?to?90%?battery?capacity?in?5?hours(standard)
?
Dependent?on?the?capacity?of?external?batteries (long?backup?time)
AC	Output?system	Single?phrase&earth?ground
?
Output
?	Output?voltage	220/110Vac±3%(inverter?output)
?	Output?frequency	50/60±5Hz(normal)???50/60Hz±1%(abnormal)
?	Dynamic?voltage?transient?range	<5%
?	Dynamic?transient?restore	<?60ms
?	Waveform	Sine?WaveTHD<3%(linear?load)?Sine?WaveTHD<8%(nonlinear?load)
?	Input?powerfac
