LED Regulated Switching Power Supply With 150W 24V 6.25A Output
- T/T L/C D/P D/A
- 7 days
You May Like
-
Regulated Switching Power Supply 12V 12.5A Metal Case Power Adapter
-
DC 5V 30A Aluminum Case Switching Power Supply For LED Display
-
120W 36V Constant Voltage Regulated Switching Power Supply For LED
-
Universal Regulated Switching Power Supply 120W 24V 5A DC Output
-
LCD Monitor Power Supply 12V 120 W For LED Lighting Driver
-
Iron Case Regulated Switching Power Supply 36V 2.8A Constant Voltage
Product Details
| Brand Name | Xingweiye | Place of Origin | China | |
| Model Number | HT-150-24 |
Product Description
Certification:CE RoHs FCC
LED Regulated Switching Power Supply With 150W 24V 6.25A Output
Quick Detail:
9 years production experience in power supply. 3 senior engineers with over 15 years experience in this field Low power consumption, high reliability Protections: Short circuit/Over load/Over voltage 100% full loading burn-in test All products have been checked and packaged in good condition before dispatchDescription:
150W 24V6.25A POWER SUPPLY
Universal AC Input (full range)
Dimension: 159*97*38mm (L\'W\'H\')?
Cooling by free air convection
Applications:
1, Digital and electronic products
2, Fiber transceivers, game player, LED, CCTV camera;
3, Electrical Equipment, Instrumentation
4.Industrail Equipment
5, Communications and security products;
6.LED Strip Lighting/ LED lamp / LED Lights
7.LED Display,etc.
Specifications:
|
Model?number |
HT-150-24 |
|
|
Input |
Input?voltage |
AC90-135V/170-264V ?50/60Hz |
|
Output |
Max?power |
150W |
|
Output?voltage |
DC?24V??+?/?-?5% |
|
|
Ripple?wave |
(mVp-p):??<10% |
|
|
Temperature?coefficient |
±0.02%/°C |
|
|
Setup rise hold up time |
200s? 100s? 30s |
|
|
Protection |
Overload?protection |
105%-150%vA,automatic?recovery |
|
Short-circuit?protection |
Once?short-circuit?protection,?automatic?recovery |
|
|
Over-voltage protection |
115~135% |
|
|
Insulation |
Withstand Voltage |
Input and output internal1.5KVAC,Input and enclosure1.5KVAC,Output and enclosure0.5KVAC |
|
Isolation resistance |
Input and output internal: Input and enclosure, Output and enclosure500VDC/100MΩ |
|
|
Environment |
Working?temperature |
0°C-40°C,10%-90%RH |
|
Store?temperature |
-10°C~ +60°C,10%-90%RH |
|
|
Size |
Size |
159*97*38mm |
|
Net?weight |
0.5kg |
Competitive Advantage:
1. Factory direct sales: Wholesale discounts & good quality
2. Timely delivery : 1-7 business days (depends on quantity)
3. OEM and ODM Service.
4. Certification: Our products are mostly certified by CE, LVD, RoHs, EMC, FCC
5. Good service: Your inquiry related to our products or prices will be replied in 24hours. Well-trained and experienced staffs to answer all your enquires in fluent English
Tag: LED power supply, Switching power supply, Constant Voltage Power Supply
