P20 Large Outdoor Full Color LED Display Advertising Board , 1800Hz High Refresh Rate
- T/T L/C D/P D/A
- 7 days
You May Like
-
P25 Large Outdoor Advertising Full Color LED Display Boards For Commercial
-
31.25MM Pixel Pitch Outdoor Full Color LED Display 250*250MM Module Size
-
DIP236 Commercial Full Color LED Display System P6 For Advertising
-
Wall Video P8 Outdoor Full Color LED Displays Billboard Waterproof With GPRS
-
DIP Electronic P10 Outdoor Full Color LED Displays Stand In Square
-
SMD P8 Outdoor Full Color High Resolution Led Display Screen For Rental
Product Details
| Brand Name | lysonled | Place of Origin | China | |
| Model Number | P20 Outdoor LED Display Screen |
Product Description
Certification:CE ROHS ISO
P20 Large Outdoor Full Color LED Display Advertising Board 1800Hz High Refresh Rate
Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:>6000 nits;
3) Scan driver:static current;
4) Module size(L*W):320*160mm;
Description:
P20 Outdoor Full Color LED Display Screen
20mm pixel pitch,1R1G1B,2500 dots/sqm,P20 Outdoor Full Color LED Display Screen creates high brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P20 Outdoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Applications Occasions:
Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Specifications:
P20mm Outdoor Full Color LED Display Screen
|
Pixel configuration |
DIP346 1R1G1B |
|
LEDs configuration |
Red:wave length: 625~630nm;1100-1300mcd |
|
Pixel pitch(mm) |
20 |
|
Pixel density(dots/sqm) |
2500 |
|
Calibrated brightness(cd/sqm,nit) |
7500 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
V60/H120 |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>1800 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
Protection grade |
IP65 front side/IP43 back side |
|
LED Drive |
Constant-current |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature(Celsius degree) |
-30 ~ 65 |
|
Storage temperature(Celsius degree) |
-35 ~ 70 |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Service |
Front and back service optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 VAC single phase(50-60Hz) |
|
Maximum power consumption(W/sqm) |
