SMD Indoor Full Color LED Displays Electronic Picture Signs , P5 800 Hz Refresh Rate

FOB Price

USD $1200 - $1700 / / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	lysonled		Place of Origin	China
Model Number	P5 Indoor LED Display Screen

Product Description

Delivery Time:10~15 working days
Certification:CE ROHS ISO

P5 Indoor Full Color LED Displays Electronic Signs , V140/H140 800 Hz Refresh Rate

Quick Detail:

1) Stable quality:Opto + Silan chipset;

2) High brightness:1500 ~1800nits;

3) Scan driver:1/16 current;

4) Module size(L*W):160*160mm;

Description:

P5 Indoor Full Color LED Display Screen

5mm pixel pitch,1R1G1B,40000 dots/sqm,P5 Indoor Full Color LED Display Screen creates comfortable brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P5 Indoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Applications Occasions:

Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Specifications:

P5mm Indoor Full Color LED Display Screen:

Pixel configuration	SMD3528 1R1G1B 3 in 1
LEDs configuration	Red:wave length: 625~630nm;300-400mcd Green:wave length: 525~530nm;600-800mcd Blue:wave length: 470~475nm;100-150mcd
Pixel pitch(mm)	5
Pixel density(dots/sqm)	40000
Calibrated brightness(cd/sqm,nit)	1800 nits(adjustable)
Calibrated brightness proportion ratio	R:G:B = 3:6:1
Contrast ratio	4,500:1
Brightness adjustment(dimming)	100 grade auto/manual-adjustment
View angle(degree)(50% brightness)	V140/H140
Color capability	4.4 trillion
Refresh rate(Hz)	>800 Hz
Frame frequency(Hz)	>60 Hz
Interface port	DVI interface(DVI connector)
Input signal	VGA, Video, AVI, MOV, MPG, DAT, VOB etc.
LED Drive	Constant-current
Lifetime(hours)(50% brightness)	100,000 hours
Signal transmission direction	Horizontal
Operating temperature(Celsius degree)	-30 ~ 65
Storage temperature(Celsius degree)	-35 ~ 70
Operation humidity(RH)	0-95%
Operation humidity(RH)	0-99%
Service	Front and back service optional
Control mode	Synchronous & asynchronous available
Communication options	Wire Ethernet, Fiber Ethernet,RF wireless,GPRS
Power	120/240 VAC single phase(50-60Hz)
Maximum power consumption(W/sqm)	800
Average power consumption(W/sqm)
