Single Phase Residential Steam Generator

Brand Name	KSA		Place of Origin	China
Model Number	KSA-E30

Delivery Time:1-3 workdays
Certification:CE

rapid steam KSA-E30 steam generators 3.0kw/220v-230v for steam bath

Quick Detail:

We produce steam generator over 10years!

Type: Wet Steam Sauna control panel: digital and optional Power output: 3.0kw voltage: 110V/220V Current: 13.6A Main Material: stainless steel tank, galvanizing and powder coated shell Color: grey green phase: single Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others Auto function: auto water inlet , auto drain, auto flushing, auto power off Shape: Cuboid Size: 405x150x280mm Room volume(cubic meter): 2~4 Usage: steam sauna room working time: 1~60 minutes or long time Heating: heat elements Power source: Electric Time Setting: 1-60mins Temperature range to control: 95 F degree~131 F degree Temperature range to show on control panel: 43 F degree ~140 F degree

3kw Residential Sauna Steam Generator 110V with single phase for steam bath

Description:

Main features: KSA-E steam generator with a host of advanced features.

Intelligent to heat by segment, fill water with steam, automatic to turn off , a self flushing cycle ,with pressure to drain. Light can be connected to controller, water inflow to magnetize and filtrate etc. Intelligent to indicate fault with the code. To show CH can working for long Can pause at working Intelligent to save two sets of temperature, can individual set time by memory

1. KSA-E steam generator have middle size to install easily. They have 304 stainless steel water tank, 304 stainless steel heating element with high quality Teflon to prevent water scale.

2.The controller has 6 bottoms to set working stages. working time 1-60mins can be adjusted or long ,the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).KSA-E steam generators feature an advanced electronic control with on board diagnostics having a series of LEDs to show each operation of the gernerator. Each generator has 3 groups of heating elements to provide sequential heating (from cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop. The group 3 alternates on and off to gently maintain the temperature without large fluctuations improving user comfort).

3.KSA-E steam generators have an auto drain down with a self flushing cycle to dump the boiler contents in a controlled manner - at the end of each steaming session the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining. Flushing and draining the boiler reduces the build up of damaging limescale, cooling the elements before the final drainage helps prolong their useful life.
Electronic controls with a digital display to enable temperatures of 30 to 60 degrees centigrade and time duration 1 to 60 minutes or continual operation with additional keys for a steam room light, keyboard lock, manual drain down etc.Safety features include boil dry protection, thermal overload safety cut out and pressure relief valve.

4.A steambath is an ancient type of bath, first made popular by the ancient Greeks and Romans. The origins of the steam bath come from the Roman bath, which began during the height of the Roman Empire. Ancient Roman baths served many community and social functions within Roman society. Everyone in Rome used Roman public baths, regardless of socioeconomic status.

Applications:

For 2~4m3 residential and commercial steam baths

A daily steam bath is a remarkable way to indulge yourself. It causes the?perspiration that is the single healthiest thing you can do for your skin. Stress and?negativity?quickly dissipate in the soft clouds of intense yet comforting heat. A few?minutes?of?steam daily, in the comfort?of your own home, is an opportunity to?improve?your?overall well-being in every way.

Specifications:

Control panel with Digital display Control panel used the advanced inducing technology Controls sauna temperature 35 degree to 55 degrees Controls sauna time 1 minute to 60 minutes or long time Intelligent to heat by segment Intelligent to fill water with steam Intelligent to do a self flushing cycle Light can be connected to controller Intelligent to indicate fault with the code Can pause at working To show CH can working for long Intelligent to save two sets of temperature, can individual set time by memory Automat
