6V DC Wall Wart Power Adapter 1200mA , 1.0A switching power adapter

6V DC Wall Wart Power Adapter 1200mA , 1.0A switching power adapter

Quick Detail:

Wall mount power adapter

Safety approvals

Compact size

Description:

Travel Charger 6W series
1) High quality, High efficiency, extra safe design
2) I/P: 100-240VAC 50/60Hz, O/P: 3-24V, 0.1-8A, 1-120W
3) RoHS, REACH, PAHs compliant
4) UL, GS, CE, C-TICK, PSE, FCC approved
5) Energy efficiency: CEC V, EUP 2011, MEPS V

?

Applications:

Mobile device

Set top box

ADSL

Chargers

Household appliance

Audio & Video products

Specifications:

Travel charger 6W series Specification
1) Rated Input: 100-240V AC, 50/60Hz
2) Operating range: 90-264V AC, 47-63Hz
3) Output voltage: Available from 3VDC to 12VDC
4) Output current: Available from 10mA to 1200mA
5) Output power: 6W max
6) RoHS, PAHs, REACH, WEEE compliant
7) 6P, NP available
8) Energy efficiency: V (CEC, EUP, ERP, MEPS)
9) Input current: 0.18A Max, 100/240VAC
10) Inrush current: 15A Max, 120VAC at max load, 30A Max 240VAC at max load
11) Leakage Current: 0.25mA max
12) Load regulation: ± 5%
13) MTBF: 50K hours at 25\'C
14) LED indicator: Optional
15) Size: 54*24*40.5mm
16) Safety standard: IEC/EN 60950-1, CSA C22.2, UL60950
?

Safety Approvals

UL/cUL/GS/CE/CB/C-TICK/CCC/PSE/FCC
?

Protections

1) Short circuit protection
2) Over voltage protection
3) Over current protection
?

Environmental requirements

1) Operating Temperature: 0-40oC
2) Storage Temperature: -20-80oC
3) Operating Relative humidity: 10-90% RH

Competitive Advantage:

High quality,

Safety approvals

Compact size

Completed protection function

Competitive price
