1.8 57mm 2 Phase torque hybrid step motor, 4 wire / 6 wire / 8 wire and 1A 36V nema 23 57BYGH stepp
- T/T L/C D/P D/A
- 7 days
You May Like
-
8 Lead wire nema 23 and 3A 48 volt 57BYGH stepper motor, 4 Phase Integrated stepping motors with 9kg
-
4 Wire, 6 wire, 8 wire and 24V / 36V / 48V 57BYGH stepper motor, 1.8 two Phase and 57mm nema 23 ste
-
4.4 kg.cm Holding Torque, 12V four Phase and industrial 6 wire Stepper Motor, 42BYG 42MM nema 17 ste
-
12V four Phase and industrial 6 wire Stepper Motor, 42BYG 42MM nema 17 stepping motors with 6kg.cm H
-
0.3A 12V, 4 Phase and 4 wire / 6 Wire Stepper Motor, 42BYG450 and Nema 17 torque stepper motor
-
Custom nema 17 and 4 Wire / 6 Wire Stepper Motor, 42mm and 4 Phase 0.3A 12 volt stepper motor for em
Product Details
| Brand Name | CW | Place of Origin | China | |
| Model Number | 57BYG250-112 |
Product Description
Certification:CE, ISO9000, SGS
?1.8° 57mm 2 Phase torque hybrid step motor, 4 wire / 6 wire / 8 wire and 1A 36V? nema 23 57BYGH stepper motor
Description
Genaral Specification
Step Angle ------------------- 1.8°±5°
Temperature Rise ------------- 80℃max
Ambient Temperature -------- -20℃~+50℃
Insulation Resistance--------- 100 MΩ Min. , 500VDC
Dielectric Strength: ------------ 500VAC for 1minute
Shaft Radial Play --------------- 0.02Max. (450g-load)
Shaft Axial Play ----------------- 0.08Max. (450g-load)
Detailed Product Technical Date Sheet
|
Model |
Step Angle(°) |
Motor Length (mm) |
Rated Current? (A) |
Phase Resistance (Ω) |
Phase Inductane (mH) |
Holding Torque (N.cm Min) |
Lead Wire (No.) |
|
57BYG450-40 |
0.9/1.8 |
41 |
2 |
1.5 |
1.4 |
3.5 |
4/6/8 |
|
57BYG450-50 |
0.9/1.8 |
51 |
3 |
1 |
1.5 |
7 |
4/6/8 |
|
57BYG250-56 |
0.9/1.8 |
56 |
1 |
1.4 |
4.5 |
6.5 |
4/6/8 |
|
57BYG450-56 |
0.9/1.8 |
56 |
3 |
0.9 |
1.3 |
9 |
4/6/8 |
|
57BYG450-76 |
0.9/1.8 |
76 |
1.5 |
5 |
1.05 |
14.8 |
4/6/8 |
|
57BYG450-84 |
0.9/1.8 |
84 |
3 |
1.1 |
2.5 |
16 |
4/6/8 |
|
57BYG450-102 |
0.9/1.8 |
102 |
3 |
1.5 |
3.1 |
23 |
4/6/8 |
|
57BYG450-112 |
0.9/1.8 |
112 |
3 |
1.8 |
3.8 |
25 |
4/6/8 |
Detailed Product Structure Chart
?Competitive Advantage
The above are just representative products, the derivative can made according to customs demands.
