120W CCTV Power Supplies with 9 channel , 24V Power Supply 5A

????????????Model

24VAC5A9P

Power

120W

Metal Case Dimension

24.5×20.8×8.7cm

Net Weight

3.95kgs

Input

Input Voltage

110/220VAC

Input Voltage Frequency

50Hz-60Hz

Output

Output Voltage

24VAC±5%

Output Current

5A, 9 channels for 9 sets load

Fuse

Type /Rating

PTC? 1.1A/60V

Over Current Protection

When over current occurs, the corresponding channel output will automatically switch to self-protection status, and the other channels output will work normally. When the fault is cleared, it will switch back to normal.

Short-circuit Protection

When short-circuit occurs, the individual PTC fuse will break the circuit. When the fault is cleared, it will switch back to normal automatically.

Circumstances

Working Temperature

0℃-+40℃

Storage Temperature

-20℃-+85℃

RH

5%-95%

Heat Release

Natural heat dissipation

Connection

Input

Three-pin socket

Output

9 channels output
