3 Axis Bracket CMOS CCTV Camera, Plastic Dome Camera with 10m Distance, 600TVL Horizontal Resolution

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Sunchan		Place of Origin	China
Model Number	DM-839M

Delivery Time:7-10 business days
Certification:CE

3 Axis Bracket CMOS CCTV Camera, Plastic Dome Camera with 10m Distance, 600TVL Horizontal Resolution DM-839M

Description:

Plastic Dome Camera, CCTV CMOS Camera,600TVL High Definition

Super Backlight Compensation

3 Axis Bracket inside the camera

Applications:

Indoor? with enough light, like office, warehouse, convenient store

Specifications:

Model:	DM-839M
VIDEO
Imaging Device	1/3\" Korea Pixel Plus CMOS
Total Pixels	PAL:795(H)×596(V) NTSC:811(H)×508(V)
Effective Pixels	PAL:752(H)×582(V) NTSC:768(H)×494(V)
Scanning System	2:1 interlace
Synchronization	Internal
Frequency	H:15.625KHZ/V:50HZ
Horizontal Resolution	Color:600TVL
Min. Illumination	Color:0.5Lux, B/W: 0.1Lux (IR Off)
S/N Ratio	63.8 dB(AGC Off)
Video Output	CVBS:1.0Vp-p/75Ω? composite
LENS
Focal Length	3.6mm
Max.Aperture Ratio	1:F1.6
Angular Field of View	D:90°/H:68°/V:50°
Focus Control	manual
Lens Type	fixed iris
OPERATIONAL
Gama Correction	R0.15
Electronic Shutter Speed	PAL:1/50~1/100,000sec,NTSC:1/60~1/100,000sec
BLC	Super Back Light Compensation
Distance	10M
ENVIRONMENTAL
Operating Temperature/Humidity	-10℃? -? +50℃(-50°F~+122°F)/Less than 90% RH
ELECTRICAL
Input Voltage/Current	DC12V??? +10%
Power Consumption	750mA
Adapter Requirement	DC12V?? 1000mA
MECHANICAL
Color/Material	Black/plastic
Bracket	3 axis bracket inside
Dimensions(W×H×D)	127.2×90.6mm
Net Weight	0.3kg

Competitive Advantage:

600TVL with high performance
