High quality ISO certified Stainless Steel Grating (FACTORY)
- 50000 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Platform floor galvanized steel grating
-
ISO certified stainless steel grating (FACTORY)
-
galvanized steel floor grating,flooring grating,galvanized steel grating
-
Hot-dipped Galvanized serrated steel bar gratings/ Galvanized and welded Steel Platform / Serrated Steel grating
-
Welded Galvanized Steel Grating Factory
-
Hot dip galvanized steel grating(Factory)
Product Details
| Brand Name | HRT | Place of Origin | China | |
| Model Number | HRT-07 |
Product Description
1) Bearing Bar (Load Bar) Specifications (mm):
The specification of plain type and serrated type bearing bar is 20 x 3 to 100 x 10;the specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc.
2) Bearing Bar Pitch (center to center):
12.5, 15,25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended,
America standard is available <1'' x 3/16'', 1 1/4'' x 3/16'', 1-1/2'' x 3/16'', 1'' x 1/4'', 1-1/4'' x 1/4'', 1 1/2'' x 1/4''(19-w-4),(19-w-2) and so on.>
3) Cross Bar Pitch (center to center):
38, 50, 76, 100, 101.6mm etc, also be according to client's requirement and 50, 100mm are recommended, America standard is available.
4) Material:
Mild Steel (Low Carbon Steel) or Stainless Steel
5) Surface Treatment:
Untreated, Painting or Hot dip Galvanizing
