UHG GEN2 RFID Reader Support 4channel Antenna for Parking Sytem, Inventory Tracking Systems (RFID403)

RFID403 is a high performance UHF RFID fixed reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system

Specifications:

Self-intellectual property

Support ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag

902~928MHz frequency band(frequency customization optional)

FHSS or Fix Frequency transmission

RF output power up to 30dbm(adjustable)

4 SMA antenna Port

Support auto-running, interactive and trigger-activating work mode

Low power dissipation with single +9 DC power supply

Support RS232, RS485, TCPIP interface

Built-in LED, Buzzer, GPIO and Relay development.

High reliability design

Power Supply: 8-12V

Current Dissipation: 600-1500mA

Operating Temp:-10 ~55Celsus degree

Storage Temp:  -20 ~75Celsus degre

Frequency: 902-928Mhz

Effective Distance: 8-10m (also depends on antenna, tag and environment)

Size: 235×235×57mm

Weight: 2.5KGs

Application:

logistic management/ warehouse control / Parking system / automatic production management / library system etc
