Mini 1-Port Tab Up Transformer RJ45 USB Connectors for Telecommunication in 0 to +70

Mini 1-Port Tab Up Transformer RJ45 USB Connectors for Telecommunication in 0℃ to +70℃

1x1?Tab?Up?Transformer?RJ45?With?USB ?KRJ-21USBNL

Description:

RJ45 ,in order to keep good touch between gold finger and crystal head, should paint the gold on the surface,there is 6u,15u,30,50u,usually use 6u, according to customer’s request and cost to proceed, gold finger insert and pull life should be 750 times above.

Specifications:

.Insertion Loss :1-100MHZ -1.0dBmax

.Rturn Loss : 1-30MHZ -16.0dBmin

? ? ? ? ? ? ? ?30-60MHZ -14.0dBmin

? ? ? ? ? ? ? ?60-80MHZ -10.0dBmin

.Cross Talk :1-30MHZ -40.0dBmin

? ? ? ? ? ? ? 30-60MHZ -35.0dBmin

? ? ? ? ? ? ? 60-80MHZ -30.0dBmin

.CMR:1-100MHZ -35.0dBmin

.Hi-Pot:1500V AC 6S 1mA

.Turn Ratio :1CT:1CT±3％

.OCL:350uH＠100KHZ 100Mv 8mA DC

.Contacts:0.35mm thick phos bronze plated with 6u’gold in contact are

.Housing Material:PBT Black

.Operating temperature rang :0℃ to +70℃

Applications:

? Integrated RJ45 connector main used to :

? 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,?internet set- top box,internet camera,netbridge,computer,telecommunication,

MODEM,HomePNA,DSL／ADSL and so on.
