constant voltage switching power supply, led transformer for UPS / VCD / DVD / chargers

HS-200W-12V

Output	Output Voltage	12V
Output Current	16.6A
Output Current range	0~16.6A
Output Power	200W
Wave and noise	180mVp-p
Setup,rise,holdup time	200ms,100ms,20ms
Input	Input Voltage range	90~132VAC/180~264VAC,47~63Hz 255~373VDC
AC Input Current	4.5A/115V AC 2.5A/230A
Efficiency	80%
AC impulse Current	50A/230VAC
Leakage Current	<3.5mA/240VAC
Protection	Overload Protection	115%~135%? Hiccup mode,auto-recovery
Environment	Working temperature,moisture	-10°C ~+60°C ,20%~90% RH
Store temperature,moisture	-20°C~+85°C, 10%~95% RH
Size	size	199(L)110(W)50(H)mm
Net weight	0.85kg
safety	Against Voltage	I/P-O/P: 1.5KvAC 1min I/P-FG: 1.5KvAC 1min O/P-FG: 0.5KvAC 1min
Insulation impedance	100M Ohms/500VDC
Certificate	CE ,ROHS
Packing	24pcs

Feature:

1,Low price and high reliability

2,AC input power suitable for the world

3,High efficiency and low operation temperature

4,Soft-start current can reduce the AC input impact effectively

5,With short-circuit and over load protection

6,Compact size, light weight
