Industrial Automatic Bottle Label shrink sleeve labeling machine systems for Baby food

Brand Name	Sunwell		Place of Origin	China

Delivery Time:7-15days
Certification:CCC, CE, RoHS, UL

Industrial Automatic Bottle Label shrink sleeve labeling machine systems for baby food

Container forms have become diverse and labels are now used for many types of containers such as plastic, glass, or metallic ones. When using labels, illustrations and logos are printed on the reverse side of a film. Labels are very effective for enhancing a products appeal, since the whole label can be used to display the design.

Applications:

Food and Beverage (Sauces, Spread, Prepared meal, Snacks, Soft drinks, Fruit juices, Water, Alcoholic drinks, etc.) Dairy (Milk-based drink, Yogurt drink, Yogurt Cup, Coffee creamer, Ice cream, etc.) Nutrition product/Supplement (Baby food, Healthy foods, etc.) Home care (Laundry, Fabric care, Detergent, Cleaning products, etc.) Personal Care (Hair care, Soap and Bath products, Oral care, Skin care, Cosmetics, etc.)

Specifications:

TB-450 Sleeve Labeler Configurations: PLC controller: Omron Stepping motor: Taida Step drivers: PANASONIC Transducer: Japan KEYENCE Touch screen: Taiwan Weinview

TB-450 Label Sleever Technical Parameters:

Size: 2000L*950W*2000H (mm) 2 meters conveyor belt include (motion and scraping belt are including) Gross weight: about 400KG Bottle diameter: 25－95mm (max) Bottle Height: 15-200mm Bottle type: round Bottle. Label length: 30~100 (mm) Label thickness: 0.030-0.080mm Paper pipe interior span: 3-10 ‘’ Machine speed: 450BPM (subject to label length) Power: AC 3￠380V Consumed power: 3KW

RSS-2000 Steam Shrinker Technical Parameters:

Size: 2000L*570W*900-1600H (mm) Power: AC 3￠380 steam consumed capacity: 20-100 KG/H steam pressure: 0.15-0.4MPa Fan-power: 0.45-0.75KW

DZFZ-36KW Automatic Electric Steam Generator Technical Parameters:

Rating: 36KW Power: 380V Consume power: 0.4Mpa Saturation steam temperature: 152°C Rating quanlity of steam occur: 45Kg/h Size: 1300L*700W*1000H (mm)

Features:

Full stainless steel protective of main engine the machine is fully waterproof and stainless; Adjustable blade base: Unique cut off, double blade for long using life Positioning center guiding pole: stable label guiding and delivering; Screw rod of separate bottle: stable transportation of bottles; Label brushing set: more accuracy of label-casing precision; Label control sensor shelf: original creation tail surface and sensor are combined to improve the precision of cutting the material. Human touch screen: Auto Show cause of the malfunction, operating more humane Touch-screen: operation humanization
