Product Details
| Brand Name | S.H.M | Place of Origin | China | |
| Model Number | SHV |
Product Description
Certification:ISO9001:2008
1/2\" BSP, BSPT, NPT ?±1 % V - Shape V - Line Industrial Glass Thermometer For Sea Water
Features:
* The casing is V shaped, gold-coloured anodized aluminium. The thermometers are adjustable to any desired viewing position. Straight thermometers locked by a brass nut, angled thermometers have a grooved adapter piece with a set screw, the advantage for this is, when mounting the thermometer, it is not necessary to turn the Casing. The inserts are prismatic glass which are blue or red spirit filled (mercury filled over 200oC), and the pockets are brass or stainless steel with a 1/2\"BSP male thread as standard.
* Temperature Ranges: -60 up to 600° C????
* Accuracy±1 %
Descrition:
V-line?Industrial?Glass?Thermometer?
V-shaped?Industrial?Glass?Thermometer
Model?No.?SHV
Applications:
V-line thermometers are typically used in HVAC, diesel engines, refrigeration, chemical, petrochemical plants, compressors, ship yards, turbines and power stations. The thermometers represent the highest quality available in direct mounting industrial thermometers used in many applications.
|
Model?No. |
Size?and?Form?of?Body |
Temp.Range |
Temp.Liquid |
Body |
Stem?Length |
|
SHV-01 |
110×35mm?Straight |
-60+40℃?or?C/F -30+50℃?or?C/F 0+60℃?or?C/F 0+100℃?or?C/F 0+120℃?or?C/F 0+160℃?or?C/F 0+200℃?or?C/F 0+300℃?or?C/F 0+400℃?or?C/F 0+500℃?or?C/F 0+600℃?or?C/F |
Blue or red organism
(from -60℃to 200℃) (℃ or C&F)Mercury (above 200℃/400℉) |
Aluminum?and?gold? colour anodised |
L=30,40,50, ??63,75,100, 160,200mm, etc |
|
SHV-02 |
110×35mm?90°Angle |
||||
|
110×35mm?135°Angle |
|||||
|
SHV-03 |
150×35mm?Straight |
||||
|
SHV-04 |
150×35mm?90°Angle |
Stem?Material |
Connection |
||
|
150×35mm?135°Angle |
Brass,CuNi10Fe, Stainless steel 304.316etc. |
3/8”,1/2”,?3/4” BSP,BSPT,NPT |
|||
|
SHV-05 |
200×35mm??Straight |
||||
|
SHV-06 |
200×35mm?90°Angle |
||||
|
200×35mm?135°Angle |
