different size ptfe pipes
- Qingdao Shanghai Ningbo
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | sdsenrong | |
| Model Number | SD-RP1 | Material | Other, PTFE | |
| Specification | all size accordeing to the customer's requirement | Length | according to the customer's requirement | |
| Thickness | 0.1mm-500mm |
Product Description
Specifications
insulted pipe casing for wire ,pipe for corrssive fluids,electric insulated parts used in high frequent conditions.
1,Features:
There are three types of PTFE pipes:
For a pipe with outside diameter1~25mm and thickness of wall 0.1~2.5mm,we chose imported polymized PTFE resin and process it by pressing;For a pipe with outside outside diameter25~200mm and thickness of wall 1.5~8mm,we choose suspended PTFE resin and process it by extruding ;For a pipe with outside diameter 25~1200mm and thickness of wall 5~500mm, we process it by die pressing .
2,Specifications:
TYPES | Specifications | ||
Outside diameter(mm) | Wall thickness(mm) | Length(mm) | |
Pressed pipe | 1 ~ 25 | 0.1 ~ 2.5 | Produced under requirements |
Extruded pipe | 25 ~ 200 | 1.5 ~ 8 | Produced under requirements |
Die pressed pipe | 25 ~ 1200 | 5 ~ 500 | 100 ~ 300 |
3,Main properties:
Properties | Unit | Result |
Apparent density | g/cm³ | 2.10~2.30 |
Tensile strength(min) | Mpa | 18 |
Crack elongation(min) | % | 230 |
