Product Details

Place of Origin	China
Model Number	STSJ-5A

Product Description

STSJ-5A Intelligent Electric Tetragenous Direct Shear Testing Apparatus

Application: This apparatus is used to test resisting shear strength of soil specimen. It
usually adopts four specimens under the different vertical pressure exerted on the
specimens to obtain shear stress when the specimen is destroyed.
Specification:
1. Area of soil sample:30cm²
2. Lever ratio:1:12
3. Vertical Loading: 50,100,200,300,400(Kpa)
4. Max. horizontal loading: 1.2KN
5. Shear rate: 5, 2.4, 1.5, 1, 0.8, 0.02, 0.01mm/min
6. 4 specimens in the same test
7. Working voltage: AC220V
8. Measurement: 1160x900x1160mm(main frame), 500x500x1020mm(controller), weight: 240kg
Features:

1.Stainless steel working table

2.stepping motor as pushing mechanism

3.high precision, low noise, MCU control

4.variable speed displayed by the controller, easy to operate

5.ABS vertical type controller,

6.LCD display

Direct Shear Testing Apparatus
