Home > Products > New product > GJFBZY fiber optic cable
GJFBZY fiber optic cable
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | YOUXIN | Place of Origin | China | |
| Model Number | GJFBZY |
Product Description
◇ Compact and light weight, low purchasing and construction cost
◇ Easy connect without splicing, fast and convenient
◇ Excellent tensile and crush performance, the span distance for self-support type can be up to 50m
◇ Non metallic strength member is Kevlar fiber reinforced plastic know as K-FRP
◇ Soft and flexible, good bending performance
◇ Flame retardant LSZH/PVC jacket meets relevant fire protection requirements in indoor environment
◇ Optical fiber meets the requirements of ITU-T G657A standard
◇ High carbon steel messenger wire enables the self-support type has excellent tensile strength
Description
(non-metallic strength member, flat, fire-retardant polyethylene sheath indoor cable communications) cable structure is single mode or multimode optical fiber placed in the middle of the two non-metallic reinforcement layer of flame-retardant polyethylene extruded after ethylene sheath (LSZH). GJFBZY CH (metal strengthening hanging wire, flat, flame retardant PVC sheathed "8" shape with a self-supporting outdoor optical cable communication) cable structure is GJFBZY fiber optic cable to increase the structure of metal hanging wire. The cable structure is compact and has excellent high temperature performance, strengthen the use of high-carbon steel wire hanging line, with superior tensile strength, fiber reinforcements with excellent bending properties, with low smoke zero halogen sheath material with excellent flame retardance . Products for users to access network use.
Parameter
|
Type
|
Fiber count
|
Dimension
(mm)
|
Tensile strength(N)
|
Crush (N/100mm)
|
Min bending radius(mm)
|
Weight
(kg/km)
|
|||
|
Short term
|
Long term
|
Short term
|
Long term
|
dynamic
|
static
|
||||
|
GJFBZY
|
1
|
3.1x2.0
|
100
|
50
|
2000
|
700
|
30
|
15
|
9.6
|
|
GYC8ZY
|
1
|
5.3x2.0
|
700
|
350
|
2000
|
700
|
240
|
120
|
21.5
|
|
GJFBZY
|
2
|
3.1x2.0
|
100
|
50
|
2000
|
700
|
30
|
15
|
9.8
|
|
GYC8ZY
|
2
|
5.3x2.0
|
700
|
350
|
2000
|
700
|
240
|
120
|
21.7
|
|
GJFBZY
|
4
|
3.1x2.0
|
100
|
50
|
2000
|
700
|
30
|
15
|
10
|
|
GYC8ZY
|
4
|
5.3x2.0
|
700
|
350
|
2000
|
700
|
240
|
120
|
22
|
1. The typical values in the table may be adjusted accordingly
2. Different specifications are available upon request
3. Environmental properties
Temperature range:-40~+70℃
Environmental standards: ROHS compliant
4. Fire protection: meet the requirements of IEC60332
Applications
◇ FTTH network
◇ Fiber optic communication network
