Galvanized Steel Sturcture Modular Asian Trade Container Exhibitions - Movable, Mobile

Galvanized Steel Sturcture Modular Asian Trade Container Exhibitions - Movable , Mobile

Description:

The overall size of a standard single container house is 2.4m*6m.The containers can be stacked each other to three floors and be jointed in longitudinal and transverse directions without limits. You can combine them yourself to achieve specific requirement. Public facilities such as bathroom and kitchen can be set inside the container house. Individual public WC/Shower and Kitchen can be made as well.

Cabin is consisted of ready-made floor frame, roof frame, wall panels, internal partitions and accessories. 2 workers can assemble on basic unit within 4 hours (about 14.4 square meters). It’s convenient for folding.4 units packed to one 20 feet container during delivery, so it is suitable for international transportation. ?

Applications:It has various functions for different usage, such as temporary office or dormitory, working camp living building and residential building etc.

Specifications:

I.???? Dimension(mm)＆Weight(kg)

II.?? Floor

Steel frame?????? ?????????? - made from cold rolled, welded steel profiles, 4 mm thick

????????????????????????????????? - 4 corner casts, welded

????????????????????????????????? - 2 fork lift pockets (except 30’), distance 1200mm

??????????????????????????????????? (Internal clearance of fork lift pockets: 240×80 mm)

????????????????????????????????? - Steel cross members, thickness=2mm

Insulation?????? ? ?????????? - 100 mm thick rockwool

Subfloor???????????? ? ? ? ?? - 0.5mm thick, galvanized steel sheet

Floor?????????????? ??????????? - 18mm Plywood board

????????????????????????????????? - 1.8mm PVC floor

??????????????????????????????????? Flammability class B1 - hardly combustible

??????????????????????????????????? Smoke density class Q1 - low smoke emission

??????????????????????
