Movable Prefab Container House Made From Galvanized Steel Frame for Site Accommodation

Movable Prefab Container House made from Galvanized Steel Frame and Sandwich Panel for Site Accommodation

Description:

The overall size of a standard single container house is 2.4m*6m.The containers can be stacked each other to three floors and be jointed in longitudinal and transverse directions without limits. You can combine them yourself to achieve specific requirement. Public facilities such as bathroom and kitchen can be set inside the container house. Individual public WC/Shower and Kitchen can be made as well.

Cabin is consisted of ready-made floor frame, roof frame, wall panels, internal partitions and accessories. 2 workers can assemble on basic unit within 4 hours (about 14.4 square meters). It’s convenient for folding.4 units packed to one 20 feet container during delivery, so it is suitable for international transportation. ?

Applications:Suitable for normal worker’s accommodation.

Specifications:

I.???? Dimension(mm)＆Weight(kg)

II.?? Floor

Steel frame??? ???? - made from cold rolled, welded steel profiles, 4 mm thick

????????????????????? ?? - 4 corner casts, welded

???????????????????????? - 2 fork lift pockets (except 30’) - distance 1200mm

???????????????????????? (Internal clearance of fork lift pockets: 240×80 mm)

???????????????????????? - Steel cross members, thickness=2mm

Insulation???? ? ? ?? - 100 mm thick Rock Wool

Subfloor?????????? ?? - 0.5mm thick, galvanized steel sheet

Floor??????????????????? - 18mm plywood board

????????????????????????? - 1.8mm PVC floor

Flammability class B1 - hardly combustible

Smoke density class Q1 - low smoke emission

Wear resistance factor: T level

III.???????? Roof

Steel frame??????????? - made from cold rolled, welded steel profiles, 3mm thick

??????????????????????????? - 4 corner casts, welded

??????????
